Nitris Nitrogen Generator

Nitrogen Purity %    99.5%     99%       98%        97%             96%          95%

Nitris 1                       3.78         5.62        8.5        11.24          14.04         16.80

Nitris 2                       7.56        11.24      17.0       22.48           28.08         33.6

Nitris 3                       15.12       22.48      34.0      44.96           56.16         67.2

Pressure bar (g)                   5       6        7       8       9        10       11     12      13

Correction Factor                  0.65   0.8       1      1.15   1.3     1.5     1.65    1.8       2

Data/Generator

Nitris1

Nitris2

Nitris3

Max. delivery pressure

Inlet pressure minus pressure drop (2 bar max.)

Air quality

Residual oil content<3.0 mg/m³ Pressure dewpoint < 5 ^oC

Temperature

10-40 ^oC

Connections

Air inlet, nitrogen and permeate oulet: 1”

Noise level

<45 dBa

Electrical data

120-230 Vac / 50-60 Hz

Power consumption

30W

Output Signals

Oxygen %, outlet pressure: analogue 4-20 mA – Alarm: potential free relay (max. 25V)

Input

Digital input: siwtch on/off

Dimensions (HxWxD)

1285x410x725 mm

Weight

80kg

90kg

100kg

Nitris1

Nitris2

Nitris3

Part numbers

95014

95015

95016

Maintenance kits – yearly

Oxygen transmitter

replace every 3 years
