Magnetic Latching Low Voltage DC CONTACTOR RELAY ZLJM-8C
- Shanghai/Ningbo
- T/T Money Gram
You May Like
Product Details
| Place of Origin | Zhejiang, China | Brand Name | DY | |
| Model Number | ZLJM-80C | Electricity Type | DC | |
| Number of Pole | 2 | Phase | 1 | |
| Main Circuit Rating Voltage | Other, 12VDC-120VDC | Main Circuit Rating Current | Other, 80A |
Product Description
Model No. | ZLJM—80C/ |
Contact Material | AgCdO(12) |
Contact Rating(at Resistive Load) | 80A 60VDC |
Coil Rated Voltage | 12VDC~60VDC |
Pick-up Voltage | (20~60)% of coil rated voltage |
Drop-out Voltage | (20~60)% of coil rated voltage |
Contact Pressure Drop | At most 30mV when 50A |
Insulation Resistance | Min. 100MΩ at 500VDC |
Dielectric Strength (Between Insulated Electric Parts) | 1000VAC 50 HZ/60 HZ (1 minute) |
Minimum pulse width | 500mS |
Ambient Temperature | -25℃~+60℃ |
Mechanical Life | 100,000 Operations (no load) |
Electrical Life | 6,000 Operations (at rated load) |
Coil Current | Less than 700mA |
