Relay Type Voltage Regulator(TM-1000VA)

FOB Price

USD $8 - $15 / Piece

1 Piece(Min.Order)

Supply Ability 300 Piece / Pieces per Month
Port Ningbo or Shanghai
Payment TermsT/T Credit Card

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Place of Origin	Zhejiang, China	Brand Name	ZMELEC or OEM
Model Number	TM-1000VA	Usage	Other, TM
Phase	Single Phase	Current Type	AC

Product Description

Specifications

Relay Type Voltage Stabilizer/voltage Regulator
Input 110V-270V.
Output:220V+/-8%
Over/under voltage protect,delay function.

Application:

TM Series voltage stabilizer,which has no waveform distortion,small body,light weight,high efficiency,available and convenient use, and long time operation ECT.inside structure used good material PCB and 3 or 4 or 5 Relay control the output precision and good panel design for LED indication show stabilizer situation, and many protection function according to customer requirement.also can be used for many home appliance and is one of more ideal voltage stabilizer.

Detail spec:

1.Input: AC 110V-270V

2.Output: AC 220V±10%(200V-240V)

3.Frequency:50/60Hz

4.Output Delay time Choice:Long Delay 3 Minuter/short delay 3-5 second

5.Power Factor:0.8

6.Duty Cycle:24-hours continuous.

7.Correction Speed:1500V/Min

8.Efficiency:AC-AC Better Than 98%

9.Max. Ambient Temperature:From-5 Degree to 50 degree

10.Max. Temperature rise:As per ICE Standard

Protect function:

a.Input(275V) and Output(235V) Over-voltage protect.

b.Output over-load(over current) protect

c.Short Circuit Protect

d. Temperature Rise Protect

e.Over-load arm System like UPS or Computer system

f.Build-in Rounding transformer or EI transformer

g.Surge.Spike and Lighting,harmonic filter protect

h.Delay function by front side panel one Push-Button Switch For Control Long or Short time delay

i.Four LED Indication,Normal working(Green color LED),Over-Voltage(Red Color LED),Under-voltage(Yellow color LED),Delay time(White color LED).over-load by alarm system.

Model:

TM-500VA,TM-650VA,TM-1000VA,TM-1500VA,TM-2000VA,TM-3000VA,TM-5000VA
