Android 4.3 Smart Finder Wireless Key Finder for Sumsang Galaxy 3,4 Note 3,4 With Photograph Function

Specification Description

Model

Link-490

Dimension

35*35*11.3mm

Communication   systerm

Bluetooth ver   4.0 Low Energe wireless Technology

Transport

Frequency   hopping spread spectrum method (FH-SS)

Search Range

65 ft/20m(   distance will vary depending on terrain and other factors )

Alert Range

7---30 feel   adjustable

Frequency Range

2.4-2.4835 GHz

Communication   distance

20 m (depends on   your work environment)

Battery Type

Inner 80 Ma Li-battery

Standby time

5 months

Function

l   Into the   distance alarm (about 4 to 8 m ): mobile phone, purse lost
l   Medium   distance alarm (about 8 to 12 m): luggage lost
l   A remote   alarm ( about 12 to 15 m ): pet prevent lost

Design range

1, press the   phone button---Bluetooth Tracker to alarm                                                                                                                                        2, mobile phone alarm ( More than setting distancem mobile phone and   Bluetooth Tracker to alarm at the same time )

Install mobile   phone sofeware

1, Click on the   App Store icon Free download apps                                                                                                                            2, In the search bar enter Reago ble tag

3,Input account and password and click OK                                                                                                                            4,Download is successful, click start

Establish a   connection

1, Connect:   Click to connect (Long press the Bluetooth Tracker button for 2 seconds   indicator light flash, blink, removal of matching records )

 2,   Disconnect : According the Disconnect the connection is successful

Mobile phone   looking for the Bluetooth Tracker

Buzzer: Alarm   buttons, set the distance, press once, Bluetooth Tracker to alarm and button turns   red, press it again, stop the alarm

Set range   Bluetooth Tracker looking for mobile phone

press to the   Bluetooth Tracker button 2 seconds long, lights flashing, cell phone to   alarm, press it again, alarm stop, lights out

Beyond the   settings distance or disconnect

Beyond the   settings distance, mobile phone and Bluetooth Tracker to alarm at the same   time, near to automatically eatablish a connection, stop the alarm

Stop using the   Bluetooth Tracker

press to the   Bluetooth Tracker button 2 seconds long, cell phone alarm click the   connection disconnected, the Bluetooth Tracker will be automatic shutdown in   1 minute

Package   accessories

1.1x   bluetooth music receiver                                                                                                                2.1x   mini USB power cable                                                                                                                     3.1x User manual
