Prepainted Steel Coil

FOB Price

US$ 640 - 850 / Metric Ton

25 Metric Tons(Min. Order)

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Standard	AISI, ASTM, BS, DIN, GB, JIS	Grade	SGCC,SGCD,SGCH,DX51D+Z,DX52D+Z,DX53D+Z,DX54D+Z, DC51D+Z,S350GD Q195
Thickness	0.12-1.0mm	Place of Origin	Tianjin, China
Brand Name	TJYY	Model Number	galvanized steel coil
Type	Steel Coil	Technique	Cold Rolled
Surface Treatment	Galvanized	Application	Other, for roofs, outer walls, ovens, explosive-proof steel,electrically cont
Special Use	High-strength Steel Plate	Width	500-1500mm
Length	As per customer's requirement

PRODUCTS: Prepainted galvanized steel coils

BASE SUBSTRATE	Hot dip galvanized steel (HDGI), ZINCALUME STEEL COIL
GRADE	SGCC,ENG10142, DX51D, ASTM A653
ZINC COATING	30-275g/m2
COIL WEIGHT	3-8TON
INTERNAL DIAMETER(ID)	508mm/610mm
THICKNESS	0.12-1.0mm
WIDTH	600-1500mm or as per your request
FINISHING	SMOOTH OR MATTE
PATTERN	MARBLE GRAIN OR WOOD GRAIN
PAINT	EXPOXY, POLYESTER, PVDF
TOP LACQURE COATING	15-25 um
BACK LACQURE COATING	5-10 um
CAPABILITY	50000 TON per year

Coating Chief Feature

Project	Pencil hardness	Reverse impact	T bending	Cupping test	MEK cleaning
Front/back	≥ H/2H	≥ 9J/6J	≤ 3T/5T	≥ 6mm/4mm	≥ 100time/50time

Structure of GI/PPGI

Item	Thickness	Type	Feature
Laminated film	50μm	Polyethylene	Protecting from scratchs and contamination (option)
Top coat	20μm	Polyester Fluorine	Chemical resistance and formability
Primer coat	5μm	Polyester	Workability, corrosion resistance and adhesion to the primer coating
Chemical treatment	1μm	Chromate	Good adhesion and corrosion resistance
Substrate	0.2mm-1.2mm	GI.GL,AL	GI.GL,AL
Back coat	5±2μm	Epoxy	Corrosion resistance and adhesion to the substrate

Product display
