Home > Products > stabilizer > High Quality Replaceable Sleeve Stabilizer For Oilfield
High Quality Replaceable Sleeve Stabilizer For Oilfield
- Tianjin
- T/T D/P D/A Credit Card PayPal
You May Like
-
API-7-1 8-1/2" Integral Spiral Blade Stabilizers HF3000
-
Integral blade Stabilizers/drill stabilizer manufacturer
-
API sub float valve used for oil drilling tools china
-
API drilling tools float valve model G and model F
-
API spec 7-1 sub float valve drilling tools hebei tools
-
Factory supply Float Valve Subs for oilfield
Product Details
Place of Origin | Hebei, China | Brand Name | Lockheed | |
Model Number | Replaceable Sleeve Stabilizer | Type | Other, Stabilizers | |
Machine Type | Drilling Tool | Certification | Other, API, API, ISO | |
Material | Other, Carbide, High Manganese Steel | Processing Type | Other, Forging, Casting | |
Use | Other, Well Drilling, fishing tools |
Product Description
High Quality Replaceable Sleeve Stabilizer For Oilfield
Replaceable Sleeve Stabilizer
Product Description
The replaceable sleeve stabilizer are available with two-piece and three-piece construction. The three-piece construction stabilizer is made of a body and a centralizing body(refer to sleeve replaceable). The advantage is that the sleeve can be changed quickly and easily after sleeve hardfacing is worn-out. This kind of stabilizer is especially suitable for working in directional well.
Technical specification and parameters
Bit Dia. | Drill collar | Stabilize sleeve | The body | Thread code on both ends | ||||||||||
Length | Work O. D. | Upset end Dia. | upset end length | Fishing neck length | ID | Make-up Torque (KN. m) | Over length L | Drill string type | Near bit type | |||||
Near bit Type | Drill String Type | Top | Down | Top | Down | |||||||||
8 1/2 | 6 1/2 | 480 | 214 | 190 | 200 | 600 | 71 | 6.95~7.25 | 1800~1900 | 1800~1900 | 4 1/2 IF | 4 1/2 IF | 4 1/2 IF | 4 1/2 REG |
8 1/4 | 470 | 210 | ||||||||||||
8 | 472 | 203 | ||||||||||||
7 3/4 | 455 | 197 | ||||||||||||
12 1/4 | 8 | 555 | 310 | 238 | 76 | 19.7~11 | 1800~2000 | 1800~2000 | 6 5/8 REG | 6 5/8 REG | 6 5/8 REG | 6 5/8 REG | ||
12 | 550 | 305 | ||||||||||||
11 1/2 | 540 | 292 | ||||||||||||
11 | 530 | 279 | ||||||||||||
17 1/2 | 9 | 682 | 444 | 279 | 13.85~16.55 | 7 5/8 REG | 7 5/8 REG | 7 5/8 REG | 7 5/8 REG | |||||
17 | 676 | 432 | ||||||||||||
16 1/2 | 670 | 420 | ||||||||||||
16 | 644 | 407 | ||||||||||||
22 | 2000~2200 | 2000~2200 | ||||||||||||
24 | ||||||||||||||
26 |
Product Show:
After-sale Services
Packing: Wooden case or as clients' request.
Shipping: By sea or by air for exporting goods.
We are Cangzhou Lockheed Drilling Equipment Parts Co., Ltd.
specializes in drill bits, drill pipe, for water well, oil field, construction, geothermal, directional
boring, Including three series with full model types,as follows:
Drilling Bit series: rock roller bit,tricone bit,pdc drill bit,single bit,cone bit and hole opener;
Drilling Equipment Parts series: manual tong,elevator,slips,stabilizer;
Workover Fishing Tool series: releasing spear,junk basket, overshot,reversing sub,die collar,
fishing tap etc.
Cangzhou Lockheed Drilling Equipment Parts Co., is located at the center of Beijing-Tianjin-Hebei-Shandong-Henan-Region which is adjacent to National Expressway No.106, 166km away
from Beijing, 110km away from Tianjin and 35km away from Baiyangdian, the Pearl of Huabei
Area. More convenient transport,faster delivery,and more trustful enterprise is your best choice.
Come on,join us.
Our goal:Strive for Perfection and Win by Quality.
How to order the products???
Please send the inquiry with detail item description or with Model number.
If there is no packing demand we take it as sea-way packing.
If possible please attach one reference picture to avoid any misunderstanding or any links from our website for we get a better understanding.
Can I expect a quality products???
Yes. of course.All our activities are accredited to ISO 9001:2008 and API, both in products and services, at the same time, mature production technology ensuring the quality satisfy international request.
PLs add the information in your inquiry.
1) the size of the tricone bit
2) the IADC tooth model, like 537G
3) PLs tell the drilling information of the layer.
4) PLs tell the quantity.
All Sizes and IADC Codes of Drill Bits Are Available.
Special Requirements of Different Models Can Be Customized.
