Weihua crane 5 ~200 ton bridge crane for workshop using
US$ 30,000 - 100,000
/ Set
1 Set(Min. Order)
- Tianjin Qingdao Shanghai
- T/T Credit Card
You May Like
Product Details
| Condition | New | Application | indoor material handling area | |
| Rated Loading Capacity | 5~350 ton | Rated Lifting Moment | N/A | |
| Max. Lifting Load | 900ton | Max. Lifting Height | 20m | |
| Span | 5~50m | Place of Origin | Henan, China | |
| Brand Name | WEIHUA | Model Number | QD | |
| Certification | ISO, CQM, CE, CNAS, SGS, DUNS, BV | Warranty | 12months since date of site acceptance | |
| After-sales Service Provided | Engineers available to service machinery overseas |
Product Description
Weihua crane 5~200 Ton bridge crane for workshop using
WEIHUA brand 5~200 ton bridge crane has the following advantages:
1. Light dead weight
2. Small occupied space
3. High working performance
4. Easy operation
5. Safe and reliable
6. Low operation and maintenance costs
Product Description:
Electrical
Safety Protection
Operate Mode
Product drawing and technical parameters:
| capacity | main hook | ton | 200 | |||||||||||||
| auxiliary hook | 50 | |||||||||||||||
| lifting height | main hook | m | 24 | |||||||||||||
| auxiliary hook | 26 | |||||||||||||||
| span | 16.5 | 19.5 | 22.5 | 25.5 | 28.5 | 31.5 | ||||||||||
| working duty | A5,A6,A7,A8 | |||||||||||||||
| speed | main hook | m/min | 0.28~2.8 | |||||||||||||
| auxiliary hook | 0.5~5 | |||||||||||||||
| crane travel | 5.26~52.6 | |||||||||||||||
| trolley travel | 2.5~25 | |||||||||||||||
| limit demension | L1 | mm | 730 | |||||||||||||
| L2 | 2410 | |||||||||||||||
| L | 1260 | |||||||||||||||
| h | 144 | 94 | 42 | |||||||||||||
| h1 | 50 | |||||||||||||||
| main dimension | H0 | 500 | ||||||||||||||
| H | 29896 | 2946 | 2998 | |||||||||||||
| H1 | 2550 | 2700 | 2650 | 2950 | 2900 | 3100 | ||||||||||
| B | 8110 | |||||||||||||||
| K | 4000 | |||||||||||||||
| B1 | 252 | |||||||||||||||
| F | 143 | 334 | 284 | 584 | 536 | 736 | ||||||||||
| maximum wheel pressure | kn | 381 | 394 | 406 | 419 | 430 | 441 | |||||||||
| power for all motors | kw | 143 | ||||||||||||||
| rail recommended | QU100 | |||||||||||||||
| power supply | 3 Phase A.C. 50HZ 380V | |||||||||||||||
