High quality dimmable led downlight 12W with CE ROHS
- Shanghai
- D/P D/A Credit Card PayPal
You May Like
-
NICHIA led 100-240VAC led downlight 6 inch
-
CE&RoHS LED downlight 8W 100-240VAC
-
10W dimmable led downlight with CE,RoHS, SAA,C-tick
-
high power led downlight dimmable NICHIA led 20W,100-240VAC with CE SAA,C-tick for Australia
-
NICHIA led 6 inch downlight dimmable 100-240VAC
-
led lighting CE&ROHS approved dimmable led downlight
Product Details
| LED Light Source | NICHIA | Warranty(Years) | 3 | |
| Input Voltage(V) | 100-240VAC | Lamp Power(W) | 12 | |
| Lamp Luminous Flux(lm) | 660 | Lamp Luminous Efficiency(lm/w) | 55.0 | |
| Color Temperature(CCT) | Other, 2700K,3000K,4000K,5000K | Working Temperature(℃) | -5, 35 | |
| Working Lifetime(Hour) | 45000 | Lamp Body Material | Aluminum Alloy | |
| IP Rating | IP44 | Certification | CE, Energy Star, EMC | |
| Model Number | D9010-DIM | Place of Origin | Shanghai, China | |
| Brand Name | WINSUN |
Product Description
High quality cob dimmable led downlight 12W with CE ROHS ,100-240VAC ,CE and ROHS approved ,45000 hrs lifetime with genuine NICHIA LED
Applications:
1. Area: Indoor use only.
2. Easy use and easy installation
Features:
1.NICHIA LED
2.Dimmable with most of leading edge or trailing edge dimmers, dimming level is as low as 10%,real dimming performance depends on dimmer type.
3.Perfect optical feast of eyes
4.Unique design for good heat elimination performance.
5.Long life time,
Specification:
Model Number | D9010-DIM(WW) | D9010-DIM(NW) |
Power Consumption | 12W (3×3.5W) | 12 W (3×3.5W) |
LED | NICHIA | NICHIA |
Efficiency(lm/W) | 46.7 lm/W | 55.0 lm/W |
Color Temperature | 2700±100K, 3000±100K | 4000±200K,5000±200K |
Beam Angle | 60°/ 90° | 60°/ 90° |
Input Voltage | 100-240VAC | 100-240VAC |
PFC | 0.95 | 0.95 |
Working Temperature | -5°C~+35°C | -5°C~+35°C |
Dimension | A109*58 (mm) | A109*58 (mm) |
Cutting Size | 95mm | 95mm |
Net Weight | 573 g | 573 g |
Lifetime(hr) | 40000 | 40000 |
Packaging information:
Packing: 30 boxes / carton | ||
Box | 115×115×115(mm) | 642g |
Carton | 62.5×26.5×39(cm) | 20.1kgs |
Optical Performance:
Model Number | Beam Angle | Color Temperature | Light Intensity | Lumens | CRI |
D9010-DIM(WW) | 60° | 3000±100K | 480cd | 560lm | 85 |
D9010-DIM(NW) | 60° | 5000±200K | 560cd | 650lm | 85 |
D9010-DIM(WW) | 90° | 3000±100K | 300cd | 550lm | 85 |
D9010-DIM(NW) | 90° | 5000±200K | 360cd | 660lm | 85 |
