Assembly Thermal Resistance Sensor Pt100 Temperature Sensor
- Dalian
- T/T Credit Card
You May Like
Product Details
| Place of Origin | Liaoning, China | Brand Name | Beixing | |
| Usage | Industrial | Theory | Temperature Sensor |
carton box with foam liner
Product Description
Specifications
1.Spring thermal sensor with good shock-proof performance2.Imported film resistor with stable & reliable performance
Assembly thermal resistance
Introduction
Assembly thermal resistance is usually connected with display meter, recording meter and computer, etc. to directly measure temperature of liquid, vapor, gas and solid surface ranging from -200°C to 600°C during various production process.It is widely used in petroleum, chemical industry, machinery, metallurgy, electric power, light textile ,food and other scientific department.
Theory
It is based on that temperature change of material results in charge of its resistance. When resistance value change, the working instrument will display relevant temperature
Features
Spring thermal sensor with good shock-proof performance
No compensational wire, spare cost.
High measuring accuracy
High mechanical strength, good pressure-resistant performances
Imported film resistor with stable & reliable performance
Main technical parameter
Temperature range and tolerance class
Graduation | Nominal resistance (0°C)Ω | resistance ratio(100°C) | Temperature range °C | Tolerance class |
Pt10 | 10 | 1.385 | Ceramic elements: -200~600 Mica elements: -200~420 | Class A: ±(0.15+0.2%|t|) Class B: ±(0.3+0.5%|t|) |
Pt100 | 100 | |||
Cu50 | 50 | 1.428 | -50~100 | ±(0.3+0.5%|t|) |
Thermal response time
Protective tube diameter mm | Protective tube material | Thermal response time | Length(mm) | |
WZP | Φ12 | 1Cr18Ni9Ti | 30~90S | 225,250,300 350,400,450 500,550,650 900,1150,1650 2150 |
Φ16 | 30~90S | |||
Tapered protection tube | 90~180S | |||
WZC | Φ12 | 1Cr18Ni9Ti | <180S | |
Insulation resistance
The normal temperature insulation resistance for Pt should be no more less 100MΩ.
The normal temperature insulation resistance for Cu should be no more less 50MΩ.
The testing voltage of insulation resistance should be 10~100V DC.
Nature affects
Allowing the passage of maximum current is 5mA for Pt thermal resistance,and the resulting temperature rise is not more than 0.3°C.
Company Profile
Shenyang Beixing Meter Manufacture Co., Ltd. was founded in August of 1995. We are located at Shenyang Economic & Technological Development Area and our company covers an area of 18,000sqm. Our company is specialized in manufacturing flow & level measuring instruments, chemical glass products, chemical glass pipes and special glass apparatus. Meanwhile, we also act as an agent of mechanical & electrical products, pressure instruments, chemical reagents, chemical materials, laboratory apparatus & science equipment, contract to design the instrument and meter engineering, chemical industry pipeline & laboratory auxiliary projects, process on given materials and take mechanical manufacturing. Our company has advanced production and testing equipment. We are a testing company designated by National Institute of Metrology of Liaoning Province. We have more than 180 staff members (including 2 national level engineers, 3 university technical consultants both at home and abroad, and 95 senior & intermediate technical staff members) who have been constantly dedicated to the technological development and manufacture of flow & level measuring instruments and equipment. Based on the principle of seeking technological innovation and development, our company has obtained the technological achievements of 2 patents of invention and 8 utility & new model patents and has been engaged in developing and meeting the demands of the market. Our products have been sold to the whole country and some parts of Southeast Asia. Our company has set up sales subsidiary companies in Jinan, Chongqing, Lanzhou and Xi'an, and licensing agents in other places in China to provide excellent products and good after-sales services for the customers across the country. Our company has been strictly following the requirements of ISO9001:2000 Quality Management System for years. In line with the purpose of technological innovation, quality orientation, superior products and satisfactory service, relying on the self-owned patented technology, strong research and development capability, good market reputation and well-developed sales network, our company has been constantly building product brands and has become the supporting enterprise of chemical industry, pharmacy, food, mine safety, China Northern locomotive & Rolling stock industry and the equipment manufacturing industry.
