1.5W Solar Panel

FOB Price

Negotiable / Piece

100 Pieces(Min. Order)

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

1) A grade cell used
2) Certifications:CE, Rosh, ISO 9001:2008
3) 3 years product warranty and 25 years 80% of power

MONO or POLY	POLY
Maximum power (Wp)	1.5wp
Maximum power voltage (V)	5.3
Maximum power current (A)	0.281
Open circuit voltage (V)	6.6
Short circuit current (A)	0.31
Number of cells (Pcs)	11pcs(12.5*78mm)
Size of module (mm)	176×116×17mm

Temperature coefficients of Isc (%)	0.06+/-0.01%/ °C
Temperature coefficients of Voc (%)	-(0.2+/-0.02)%/ °C
Temperature coefficients of Pm (%)	-(0.5+/-0.05)%/ °C
Temperature coefficients of Im (%)	+0.1/ °C
Temperature coefficients of Vm (%)	-0.38/ °C
Temperature Range	-40°C~+85°C
Tolerance Wattage (e.g. +/-5%)	+/-5%
Nominal Operation Cell Temperaure(NOCT)	+47°C
Surface Maximum Load Capacity	/
Allowable Hail Load	steel ball fall down from 1m height
Weight per piece (kg)	21.1KG
Junction Box Type	PV-GZX0701
Length of Cables (mm)	/
Cell Efficiency (%)	14.5%
Module Efficiency (%)	13.5%
Output tolerance (%)	+/-3%
Frame (Material, Corners, etc.)	Aluminum
Standard Test Conditions	AM1.5 100mW/cm² 25’C
Warranty	3 years product warranty and 25 years 80% of power
FF (%)	73%

We are manufaturer of solar panels and we can produce the solar panels according to customers'requirements.

If you have any interests,please feel free to contact us.
