Polycrystalline Solar Panel
Negotiable
/ Piece
100 Pieces(Min. Order)
- Ningbo
- T/T Credit Card
You May Like
Product Details
| Place of Origin | Zhejiang, China | Brand Name | RL | |
| Model Number | RL-3P | Material | Polycrystalline Silicon | |
| Size | 226*168*18 | Number of Cells | 6 | |
| Max. Power | 3W |
Product Description
Specifications
1) A grade cell used2) Certifications:CE, TUV, UL, ISO 9001:2008
3) 3 years product warranty and 25 years 80% of power
Product description: High transmission rate and Iow iron tempered glass , anti-aging EVA and high flame resistant TPT to Iaminate , and anodized aluminum alloy . Products have high efficiency , Iong life , easy installation , high wind and hail impact resistance etc .
| Model | Wp(W) | Voc(V) | Isc(A) | Vmp(V) | Imp(A) | Demension | Descrition | Weight(kg) |
| RLGP3 | 3 | 11.2 | 0.370 | 8.6 | 0.35 | 226*168*18 | 2*9 | 0.8 |
| RLGP4.5 | 4.5 | 21.6 | 0.310 | 17.2 | 0.26 | 250*193*18 | 2*18 | 0.9 |
| RLGP10 | 10 | 21.6 | 0.610 | 17.3 | 0.58 | 528*250*25 | 6*6 | 2.1 |
| RLGP15 | 15 | 22.2 | 0.960 | 17.2 | 0.88 | 410*358*25 | 4*9 | 2.3 |
| RLGP25 | 25 | 22 | 1.600 | 17.2 | 1.46 | 434*514*30 | 6*6 | 2.5 |
| RLGP30 | 30 | 22 | 1.910 | 17.3 | 1.74 | 486*514*30 | 6*6 | 3.8 |
| RLGP40 | 40 | 21.6 | 2.620 | 17.2 | 2.33 | 620*514*30 | 6*6 | 4.5 |
| RLGP50 | 50 | 21.6 | 3.180 | 17.3 | 2.9 | 612*665*30 | 4*9 | 5.2 |
| RLGP60 | 60 | 21.6 | 3.840 | 17.2 | 3.49 | 702*665*30 | 4*9 | 5.2 |
| RLGP80 | 80 | 22.05 | 5.120 | 17.2 | 4.66 | 1008*673*35 | 4*9 | 9.2 |
| RLGP100 | 100 | 21.6 | 6.610 | 17.28 | 5.79 | 1242*673*35 | 4*9 | 10.5 |
| RLGP120 | 120 | 21.6 | 7.940 | 17.28 | 6.94 | 1470*666*35 | 4*9 | 12 |
| RLGP140 | 140 | 21.96 | 8.500 | 17.46 | 8.02 | 1470*666*35 | 4*9 | 12 |
| RLGP150 | 150 | 28.8 | 7.650 | 23.04 | 6.52 | 1322*662*35 | 6*8 | 15.5 |
| RLGP180 | 180 | 30.5 | 8.430 | 24.25 | 7.43 | 1630*840*35 | 5*10 | 16.5 |
| RLGP200 | 200 | 36 | 7.940 | 28.8 | 6.96 | 1630*996*35 | 6*10 | 19.3 |
| RLGP210 | 210 | 36.44 | 8 | 29.48 | 7.12 | 1630*996*35 | 6*10 | 19.3 |
| RLGP220 | 220 | 36.52 | 8.170 | 29.56 | 7.45 | 1630*996*35 | 6*10 | 19.3 |
| RLGP230 | 230 | 36.55 | 8.370 | 29.55 | 7.79 | 1630*996*35 | 6*10 | 19.3 |
| RLGP240 | 240 | 43.2 | 7.940 | 34.56 | 6.96 | 1957*996*50 | 6*12 | 23 |
| RLGP250 | 250 | 43.6 | 7.950 | 34.56 | 7.23 | 1957*996*50 | 6*12 | 23 |
| RLGP270 | 270 | 43.9 | 8.400 | 35.28 | 7.65 | 1957*996*50 | 6*12 | 23 |
| RLGP300 | 300 | 43.2 | 9.350 | 35.28 | 8.5 | 1957*996*50 | 6*12 | 23 |
