Automotive relay 12V DC Contactor 200A WM812
- NINGBO SHANGHAI
- T/T Credit Card
You May Like
-
DC 48V Contactor Hight Voltage 100A 200A WM816
-
Automotive water lift controller auto relay 12V 24V WM AC030
-
Chair Heating Controller 12V WM HC01
-
Airflow control selector for Automotive air conditioner 12V WM CS010
-
Automotive window lift control button switch WM BS010
-
Automotive PTC High Voltage auto relay 12V 24V WM AC060
Product Details
| Place of Origin | Zhejiang, China | Brand Name | SM | |
| Model Number | WM812 | Electricity Type | DC | |
| Number of Pole | 1 | Phase | 1 | |
| Main Circuit Rating Voltage | Other, 12V | Main Circuit Rating Current | Other, 0.4A |
Product Description
P1 Features
1. Contact load capacity up to 200A;
2. Suitable for automobile starter.
P2 Ordering Information
WM812 | - 12 |
|
1 | 2 |
|
1 Part number:WM812 2 Coil rated Voltage(VDC):12: 12V;24: 24V | ||
P3 Contact Data
Contact Form | 1A(SPSTNO) |
Contact Material | Ag Alloy |
Contact Rating (resistive) | 200A/14VDC |
Max. Switching Voltage | 75VDC |
Max. Switching Current | 200A |
Max. Switching Power | 2800W |
Contact Resistance or Voltage drop | ≤50mΩ Max.(6V,1A) |
P4 Operation condition
Dash numbers | Coil voltage (VDC) | Coil resistance Ω±10% | Pickup voltage VDC(Max.) | Release voltage VDC(Min.) | Coil power | Operate Time | Release Time | |
Rated | Max. | |||||||
12V | 12 | 15.6 | 30 | 7.8 | 1.2 | 4.8W | <10 ms | <10 ms |
24V | 24 | 31.2 | 120 | 15.6 | 2.4 | |||
P5 Relay Photo
P6 Terminal Layout (Bottom views)
Insulation Resistance | 100MΩ Min.(at 500VDC) | |
Dielectric Strength | Between Contacts | 50Hz 500VAC / 1 minute |
Between Coil and Contacts | 50Hz 750VAC / 1 minute | |
Shock resistance | 147m/s2 11ms | |
Vibration resistance | 10~40Hz double amplitude 1.5mm | |
Terminals strength | 100N | |
Solderability | 235℃±2℃ 3±0.5s | |
Ambient Temperature | -40℃ ~ +85℃ | |
Relative Humidity | 85% (at 40℃) | |
P7 Wiring diagram (Bottom views)
| Dimensions / Wiring diagram (Bottom views) |
|
P8 Packing
1 pcs / inner box, 50 pcs / carton
P9 Shipping
Relay can be shipping by air, by sea and by Fedex, TNT, DHL,EMS, UPS etc.
P10 Our Factory
P11 Certificates
Our factory is ISO/TS16949 approved.
Has more than 10 patents.
P12 Equipments
Automatic and semi-automatic production lines.
Punctual delivery time:
a.We carry out your order into our well-organized production schedule, ensure your punctual delivery time.
b. Shipping notice and photos sent to you as soon as your order is shipped.
After sales service:
a. We pay high attention to your feed back after receive the goods.
b. We provide 12 months warranty after goods arrive.
c. We positively revert your complain within 48hours.
Professional sales:
a. We value every inquiry sent to us, ensure quick competitive offer.
b. We cooperate with customer to bid tenders. Provide all necessary documents.
c. We are a sales team, with all technical support from engineer team.
d. We offer OEM/ODM service.
e. Trial orders are available.
f. Sample can be supplied in 7days.
