Advantages

The advantages of the container shear as compared to common guillotine shears can be summarised as follows:

• low specific investment and running costs
• continual loading of the shear in the feed hopper with simultaneous ejection of the cut scrap - no pre-compaction by lids
• Shear control carried out by grabber crane operator no additional operator needed
• self-enclosed operation with integrated diesel engine
• collection and transport by towing vehicle for transport containers or flat bed trailer
• efficient one-man loading, cutting and removal from one or several container shears using a digger
• little space required as compared to stationary shears
• no assembly and foundation costs are needed for operation
• does not require the usual clearance for operation as it is a mobile unit
• thanks to the horizontal cut with a large guided blade carriage there is little wear
• the forces working on the blade carriage always tend towards the centre, avoiding twisting forces
• all inner surfaces have a Hardox-wear plate cover and therefore undergo less wear
• the scrap is introduced from above, due to the movement of the pre-compressor the scrap automatically slips down and the cut scrap is pushed out of the front

Applications

The container shear is particularly suited to:



• Operation at scrap yards without a power supply
• as an additional unit when capacity is reached on other scrap shears
• to prepare scrap for shredding
• processing scrap at sources of waste generation
• as a low cost alternative to guillotine shears when using several container shears beside one another with a scrap handling machine
• as a processing unit for impurities in commercial waste that cannot be processed further by a shredder

1	Press Box Size(L×W×H)(MM)			2400*1400*1880
2	Feeding opening size(L×W×H)(MM)			3200*2200*900
3	Hydraulic system working pressure			21.5Mpa
4	Blade length			1400MM
5	Cutting height			400MM
6	Total power			74KW
7	Power supply			220V/3HP 60HZ
8	Cycle time			2-3 times/min
9	Motor	Model	Y250M-6	Power	37KW
		Nominal Speed	1470R/MIN	Quantity	2Sets
10	Hydraulic Pump	Model	HY250Y-RP	Pressure	31.5Mpa
		Outflow	250ml/r	Quantity	2Sets
11	Cooler system	Model	FCE-50P-D	Quantity	1Set





Production Processing



GAODE Hydraulic Machinery has been a trusted name in the waste recycling equipment industry for over a decade as a dedicated Chinese manufacturer of scrap metal recycling equipment, our flagship products includethe shear baler, scrap baler, scrap shear, and recycling crane. In addition to scrap metal processing equipment, we also supply horizontal baler and vertical baler for compacting plastic, paper, cardboard, straw, textile and more types of wastes.

Our company was first inaugurated in 2003.We have combined advanced production and testing instruments with state-of-the-art manufacturing techniques to yield outstanding product quality.

Our GAODE brand has received critical acclaim both domestically and overseas. As a trusted waste recycling equipment manufacturer, we have successfully passed the certification of both the TUV and the ISO9001 Quality Management System. We are currently in the process of obtaining the approval of European standards such as CE and UL.

Company Show

The Finished Products

Fair Show

Certification

6months guarantee for whole machine

24hours technical support by email

Calling or door to door service

User manual and detailed video
