Home > Products > solar panel > 260Watts Solar Panels With Supply Direct From Solar Power Plant
260Watts Solar Panels With Supply Direct From Solar Power Plant
USD $0.75 - $0.85
/ Watt
1500 Watts(Min.Order)
- 300000 Watt / Watts per Month
- Shanghai
- T/T D/P D/A Credit Card
You May Like
-
310W-335Watts Solar Panels /Soalr cells Supplied Directly From Solar Power Plant
Quality Choice
-
Solar Module /Solar Panels 180-210Wp/Mono 72cells
-
250W-280Watts Solar Panels /Soalr cells Supplied Directly From Solar Power Plant
-
Solar Panels /PV Module 140-165W/Mono 36cells 156mm
-
Solar Panels /Soalr cells 80-100W/Mono 36cells 125mm
-
18V 30W polycrystalline silicon solar module specifications,10 years warranty solar panel price polycrystalline
Product Details
| Place of Origin | Anhui, China | Brand Name | JN | |
| Model Number | SR156mm260W | Material | Monocrystalline Silicon | |
| Size | 1640*992*45mm | Number of Cells | 60(6*10) | |
| Max. Power | 335Wp |
Product Description
Specifications
1.Max. System Voltage 1000V2.Mono 72cells solar panel
3.Warranty for more than 10years
4.17.1%Module Efficiency
Soalr panel /Soalr cells with 260w 60cells 156mm
| Electrical Characteristics | | |||||||
| Characteristics | SR156M-250 | SR156M-260 | SR156M-270 | SR156M-280 | ||||
| Maximum power at STC (Pmax) | 250Wp | 260Wp | 270Wp | 280Wp | ||||
| Open-Circuit Voltage(Voc) | 38V | 38.3V | 38.7V | 39.0V | ||||
| Optimum Operating Voltage(Vmp) | 31.2V | 31.8V | 32.4V | 33.0V | ||||
| Short-Circuit Current (Isc) | 8.65A | 8.77A | 8.89A | 9.01A | ||||
| Optimum Operating Current(Imp) | 8.02A | 8.17A | 8.33A | 8.48A | ||||
| Module Efficiency | 16.50% | 17.10% | 17.70% | 18.30% | ||||
| Solar Cell Eficiency | 17.25% | 17.75% | 18.25% | 18.75% | ||||
| Operating Temperature | -40°C to + 85°C | |||||||
| Maximum System Voltage | 1000V DC | |||||||
| Seriec Fuse Rating | 16A | |||||||
| Power Tolerance | ±1.5% | |||||||
| STC : Irradiance 1000W/m² , Module temperature 25°C,AM=1.5 | ||||||||
| Mechanical Characteristics | ||||||||
| Solar cell | Mono -crystalline 156×156mm (6inch) | |||||||
| No.of cells | 60(6×10) | |||||||
| Dimensions | 1640×992×45mm | |||||||
| Weight | 20kg | |||||||
Bitmap
| 3.2mm tempered glass | |||||||
| Frame | Anodized aluminium alloy | |||||||
| Junction Box | PV-RH701 (TUV) | |||||||
| Temperature Coefficents | ||||||||
| Temperature Coefficents | ||||||||
| Temperature Coefficents | ||||||||
| Nominal Operating Cell Temperature (NOCT) 45±2°C | ||||||||
| Temperature Coefficent of Pmax -(0.47±0.05)%/°C | ||||||||
| Temperature Coefficent of Voc -(0.34±0.01)%/°C | ||||||||
| Temperature Coefficent of Isc -(0.055±0.01)%/°C | ||||||||
| WARRANTY | ||||||||
| Manufacturing | 10years | |||||||
| Power production | 90% =12 years | |||||||
| 80% =25 years | ||||||||
