Product Details

Condition	New	Type	Impact Crusher
Capacity(t/h)	****	Place of Origin	Shanghai, China
Brand Name	siveo	Model Number	Y3S1860F1214

Product Description

Specifications

1.large conveying amount,simple structure Mobile Crusher Station
2.Mobile Crusher Station / crushing equipment / Mobile Crusher

Mobile Crusher Station

      Mobile crushing station is a new rock crushing equipment researched and developed by our factory. It greatly expands the concept of rough break operation. Its design aim is to consider the position of customers, to eliminate the obstacles in crushing facilities and the environment. Really provides high-efficiency and low cost project hardware to customer. Mobile crushing station has such outstanding performances:
    (1) PE Series high-performance crusher.
    (2) The integration feeder and vibrating screen with crusher.
    (3) Belt conveyor under the screen. Vibrating screen and crusher integrated on-board.
    (4) Steering traction axis, convenient highway transportation and entry working site.
    (5) Vehicle installation support. Easy to install.
    (6) Vehicle-mounted electric motor and control box integration.
Technical Parameters of Tire-type mobile impact crusher station:

Model	Transportation Length (mm)	Transportation Width (mm)	Transportation Height(mm)	Max Height (mm)	Max Width (mm)	Belt Conveyor Height	Tire Equipment	Weight (T)
Y3S1548F1010	12500	2500	4000	6000	2800	4000	Biax	42
Y3S1848F1210	12500	2800	4500	6500	3000	4000	Biax	46
Y3S1860F1214	13500	2800	4500	6500	3000	4200	Three Axle	51
Y3S2160F1315	14000	3000	4800	6500	3200	4200	Three Axle	57
Y3S1848F1210Z	18000	2800	4500	6700	3000	4000	Four Axle	55
Y3S1860F1214Z	18000	3000	4500	6700	3000	4200	Four Axle	61

Vehicle Specification:Underpan Height:1650MM, Height difference of Wheel and Underpan:380MM

Model	Vibrating Screen Model ?	Impact Crusher Model	Size of Belt Conveyor below screen	Size of Belt Conveyor Above screen	Size of Belt Conveyor	Capacity(t/h)	Power (kw)
Y3S1548F1010	3YZS1548	PBF1010	B500X7M			30-275	70-90
Y3S1848F1210	3YZS1848	PBF1210	B650X7M			56-330	128.5-150.5
Y3S1860F1214	3YZS1860	PBF1214	B650X8M			65-586	154-190
Y3S2160F1315	3YZS2160	PBF1315	B800X8M			81-720	210-297
Y3S1848F1210Z	3YZS1848	PBF1210	B650X7M	B650X16M	B650X10M	56-330	148-168
Y3S1860F1214Z	3YZS1860	PBF1214	B650X8M	B800X16M	B800X11M	65-586	182-218
