1200t/d Five Stage Cyclone Preheater

FOB Price

USD $6 - $65 / Set

6 Sets(Min.Order)

Port shanghai china
Payment TermsT/T L/C D/P D/A

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Place of Origin

Shanghai, China

Brand Name

sievo

Product Description

As an important equipment of preheater system , Five Stage Cyclone Preheater with calciner is one of the main equipments of clinker production.It is called new dry process production equipments.

Five Stage Cyclone Preheater and precalciner is the kernel of the new type dry-process kiln system.

Preheater and calciner are adopted for preheating of the raw meal and decomposition of the calcium carbonate.The decomposition rate of the raw meal off the system into kiln can be as high as 90% above.By this way,the function of kiln is limited to clinker can burning at high temperature,so the size of the kiln be smaller.Preheater and calciner are two key equipments of the clinker production.It makes strong influence on the stabilization of clinker burning process and the quality and quantity of the product.Preheater kiln and cooler are three main equipments of cement plants.

Preheater system is composed ,

cyclone,

gas duct,

chute,

calciner,

high,temperature adjusting valve,

quenching chamber

and smoke chamber etc.

Technical Parameters of Cyclone Suspension Preheater Decomposition Furnace System

	Equipment	Model	Weight of heat-resistant steel (Kg)
	Equipment	Model	1Cr18Ni9Ti	2Cr25Ni20Si2
Preheater	Ⅰ	2-φ3800	6400
	Ⅱ	φ5700	3204
	Ⅲ	φ6100	3400
		2-φ4400	70	4086
		φ6100	70	2313.6
Uprising pipeline	Ⅰoutlet flange	2-φ1440
	Ⅱ-Ⅰ	φ2720	120
	Ⅲ-Ⅱ	φ2900	106
		2-φ2250	140
		φ3000	150
Decomposition furnace	SC	φ3200	362	116
	MC	φ4450	566	98
	Connection tube	2450×2450	65
	Gooseneck tubing	2800×2800	427
	Coal nozzle
Discharge pipeline	Ⅰ	2-φ650	170
	Ⅱ	φ650	68
	Ⅲ	φ750	83
		2-φ650	179
		φ750	193
Expansion joint	C1	PZJ450	251.6
	C2	PZJ450	291.6
	C3	PZJ550	133
	C4	PZJ450	167.6
	C5	PZJ450	110
	Decomposition furnace
Accessories	Expansion joint	2-φ1345	150	830
	Smoke chamber		360	1350
	Mixing chamber
Valve	2	R350	100
Valve	6	R450		280
