Product Details

packing machine
1.Many apperance for your choice
2.high-speed, efficiency
3.Good quality, complete service

packing machine

Function and Trait

1. Use the combination chain style on feeding table.

2. Adopt planet style electrical adjustment of 360 degrees whatever operating and stop quickly and accurately.

3. Ink roller can be detached automatic from printing plate to avoid damage the printing plate.

4. Inker roller equipped the separately turn device to prevent ink dried when machine stop.

5. Pneumatic lock, electrical divides

6. With Pneumatic diaphragm pump to supply ink

7. Main transmission gears are made by 45#steel after high frequency quenching.

8. Drive part adopt sprinkle lubricating system, improve the precision and serve life of machine.

Technological Parameter

Model	roller diameter(mm)	Paperpassing width(mm)	Effective Printing area(mm²)	Total weight of machine(about kg)	Motor power(kw)
YFQ-1800	420	1750	1500×1300	4500	4.0
YFQ-2000	420	1950	1700×1300	5000	4.0
YFQ-2200	420	2150	1900×1300	5500	4.0
YFQ-2500	420	2450	2200×1300	6000	4.0
YFQ-1800	480	1750	1500×1470	5000	4.0
YFQ-2000	480	1950	1700×1470	5500	4.0
YFQ-2200	480	2150	1900×1470	6000	5.5
YFQ-2500	480	2450	2200×1470	6500	5.5
YFQ-2800	480	2750	2500×1470	7000	5.5
YFQ-3000	480	2950	2700×1470	7500	7.5
YFQ-2500	530	2450	2200×1600	7500	7.5
YFQ-2800	530	2750	2500×1600	8000	7.5
YFQ-3000	530	2950	2700×1600	8500	7.5
