MQJ corrugation rotary die-cutting machine

Specifications

MQJ corrugation rotary die-cutting machine

Use and Characteristics:

This machine adopts chain feeding system and double roller rotary type. It can complete all procedures of slitting, creasing, corner cutting and hit special hole at one time. The functions of die-cutting E flute corrugated cardboard.

1. Automatic compensation of line speed can ensure die-cutting size same and right.

2. With automatic repairing function of upper roll, prolong rubber use life.

3. Adopts good-quality super durable polyurethane rubber from Taiwan.

4. Automatic horizontal movement in 40mm

5. The upper and low roller made of cast steel and chrome plated, the thickness is 30mm.

6. Body wall made of cast iron, thickness is 50mm.

7. Pneumatic with manual lifting cylinder system.

8. Equipped with digital counter

9. With an optical sensor, when feeding board, upper roller will down and press, without board will separate automatically.

10. Spray lubrication system.

11. Die roller adopts manual digital phase adjustment in 360 degree (optionsl: electric ajust phase adustmetn)

11. It is advantage of high precision, easy to operate, long service life and low cost.

12. Provide air compressor.

Main Technology Parameters:
