1000W Solar Inverter
- shanghai
- T/T
You May Like
Product Details
| Place of Origin | Shanghai, China | Brand Name | shanghai brilliant | |
| Model Number | 800W solar inverter | Specification | Normal | |
| Application | Commercial | Output Voltage (V) | 110V/220V | |
| Load Power (W) | 800w 1600w 2400w 3200w 4000w | Solar Power (W) | 1000W | |
| Work Time (h) | 24 Hours |
Product Description
PRODUCT FEATURES:
•Featured with high reliability and low failure rate by using the advanced Double-CPU single chip intellectual control technology.
•Pure sine wave output.
•Small, light and artistic, benefited from adopting the SMD pastern technology.
•Cooling fan is intellectual controlled, and its working status is controlled by CPU, which mostly
increased its service life and helps to save the power consumption, improve work efficiency and lower
the working noise.
APPLICABLE FOR:
•Industrial intellectual control system.
•Small sized emergency power supply system.
OUTPUT OUTPUT VOLT 100/110/120/220/230/240VAC
CONTINUOUS POWER 1000W
SURGE POWER 2000W
WAVEFORM PURE SINE WAVE
FREQUENCY 50Hz/60Hz
AC REGULATION LOW & HIGH 10%
NO LOAD CURENT DRAW <0.8A
EFFICEINCY >87%
INPUT USB OUTPUTt 5V
DC VOLTAGE LED DISPLAY POWER & FAIL STATUS
INPUT RANGE 10-15VDC 21-30VDC 40-60V
PROTECTION WORKING INPUT 12VDC 24VDC 48VDC
FUSE 35A 20A 15A
Low battery alarm 10.5+0.3V 21+0.5V 42±0.5V
Low battery shut down 10+0.5V 20+0.5V 40±0.5V
Over voltage shut down 15.5+0.5V 30.5+0.5V 60±0.5V
Over load shut down 1200W OVER 10 SECOND
Over heating shut down >75℃
Over Thermal shut down the output
Working Temperature BETWEEN -10℃ and +50℃
soft start
OTHER DIMENSION(L*W*H) 310*150*70mm
INNER BOX DIMENSION 390*190*110mm
CARTON DIMENSION 510*410*400mm
NET WEIGHT 3.5±0.2KG
GROSS WEIGHT 14.8±1KG
PACKING 4PCS/CTN
About us
About us
Email address:
shanghaibrilliant(at)
shanghai Brilliant Solar Co.,Ltd. was established in 2004 by some of solar, electrical & mechanical Engineers who have been working in Solar , electrical, and mechanical fields for tens of years. it has a wide background of some of mutinternatianl companies, who specialized in solar panels ,solar ECO products ,mechanism, electrical controller, hardware, hydrodynamic ,HVAC and etc. its business gets improved so fast. it is a professional ECO product manufacture. Every details of the products begin and end with their passionate attention.
They have been always making improvements on the quality for the end users, and have been always keeping a very close step to the market requirements and the new technology in order to assure that their clients, or dealers will stand in a competitive situation facing the competitive market. that is their customer oriented service.
They welcome all customized designs as based on the extended background of the experiences in ECO products ,hardware and electronics They have the ability in customized design. Hard work alone will not guarantee the quality, the constant quality and the service, so all members of their team learn to and strive to focus on the needs of the customers using creativity, commitment, pride and passion.
They accept the consequences of their actions. they admit their mistakes and quickly correct them. They bear in minds the Quality ,price and the fast delivery.
All members of their team will provide the very friendly communications, and are easy to do business with. they strives to make the contribution for a ECO world
Equipment & technology
The one who can make a solar product with a quality which can compare with the quality made in USA
Service
3, stable product quality , supply, the good faith management
5000W Pure sine wave inverte
4000W Pure sine wave inverte
3000W Pure sine wave inverte
2000W Pure sine wave inverte
1500W Pure sine wave inverte
