New Mini Gps Gsm Tracker

U-traveller Model T1/T2 GPS Tracker

Product Introduction

1. Main Features

1)  Non built-in battery design,DON’T replace battery forever.

2) Fully support owner checking and operating GPS tracker by SMS.

3) Can position even no GPS signal, with unique patent technology in the global.

4) Use independent intellectual property rights AGPS technology to quicken positioning speed.

5) Price is the lowest in the industry peers.

2. Product Pictures

3. Product Specification

1) GPS Features

Channel:Paralleled 20 Channels

Sensitivity:<-162dBm(2 times then other products)

TTFF: Cold start 45s, Hot start 3s(Positioning more rapid)

Fix Accuracy: <10m

Speed Accuracy: 0.3m/s

2) GSM Features

Frequency: GSM 900/1800/800/1900

Maximum transmission power: 1W

3) Main Features

Dimensions:85mm×52mm×14mm

Operating Voltage: 12V/24V

Maximum Operating Current: < 250mA(12V)

Standard Operating Current: < 15mA(12V)

Operating temperature: -20 °C ~ +70 °C

Humidity: 20 ~ 95%

4. Contrast Model T1 with T2

5. Product Interface Specifications

1)  Power Cable(2 lines)

2)  Function Cable(2 line)----- only apply to Model T2

6. Components
