piston air compressor for mining/air compressor head

FOB Price

USD $260 - $1,000 / Set

1 Set(Min.Order)

Supply Ability 1000 Set / Sets per Month
Port Ningbo or Shanghai

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Condition	New	Type	Piston
Configuration	Portable	Power Source	Diesel
Lubrication Style	Lubricated	Mute	No
Place of Origin	China	Brand Name	QianKun
Model Number	w2.8/5,w3.5/5,2v4.0/5	Voltage	12v
Certification	SGS	Warranty	1 year
After-sales Service Provided	Engineers available to service machinery overseas

Product Description

Specifications

air compressor head
1.Air capacity1.35-4m3/min
2.Working Pressure:5bar
3.Power:diesel engine (18.5KW/22HP)

air compressor head

product photos

What is the advantage of our piston air compressor?

1).High-strength casting to the cylinder with good abrasion resistance.
2). Imported valve plate with good abrasion resistance and long lifecycle.
3). Gorgeous bake painting by full automatic machine
4). Various air capacity and pressure types are available.

what is the specification of our piston air comrpessor?

Model	Air capacity	pressure	INSTRUCTION
W1.35/5	1.35M3/Min	0.5mpa	Air compressor with 0460fan pulley
W1.8/5J	1.8M3/Min	0.5mpa	Air compressor with 0200tank
W1.8/5	1.8M3/Min	0.5mpa	Air compressor with0220tank
W2.8/5J	2.8M3/Min	0.5mpa	Air compressor with 0250tank
W2.8/5	2.8M3/Min	0.5mpa	Air compressor with 0273tank
W2.8/5	2.8M3/Min	0.5mpa	Air compressor with 0300tank
W3.0/5J	3.0M3/Min	0.5mpa	Air compressor with 0273tank
W3.0/5	3.0M3/Min	0.5mpa	Air compressor with 0300tank
W3.5/5	3.5M3/Min	0.5mpa	Air compressor with 0273tank
W3.5/5	3.5M3/Min	0.5mpa	Air compressor with 0300tank
W2.8/5K	2.8M3/Min	0.5mpa	Air compressor with 0273tank wear-resisting
W2.8/5K	2.8M3/Min	0.5mpa	Air compressor with 0300tank wear-resisting
SF4.0/5	4.0M3/Min	0.5mpa	Air compressor with Four slot fan,clutch
W3.5/5K	3.5M3/Min	0.5mpa	Air compressor with Four slot fan,clutch
W3.2/7K	3.2M3/Min	0.7mpa	Air compressor with S Four slot fan,clutch
W3.2/7	3.2M3/Min	0.7mpa	Air compressor with double belt motor control
2V3.5/5K	3.5M3/Min	0.5mpa	Air compressor with S Four slot fan,clutch
2V4.0/5K	4.0M3/Min	0.5mpa	Air compressor with S Four slot fan,clutch
