Home > Products > Moisture Meter > VHF-Band Moisture Measurement Sensor Liquid Materials
VHF-Band Moisture Measurement Sensor Liquid Materials
- Hamburg
You May Like
Product Details
| Brand Name | PCE Inst. | Model Number | PCE-MWM 220 |
Product Description
Technical specifications: | |
Measurement range | 0 ... 100 % |
Limits of permissible absolute error of the measurements results of the mass fraction of water | 0.035 +0.05·W |
Temperature measurement range | -40 ... +150 °C |
Range of working temperatures | -20 ... +120 °C |
Operation mode continous | continuous operation |
Measurement period | 1 s |
Voltage supply - Rated / - Allowable | 24 (18 ... 36) VDC |
Consumption current, not more than | 200 mA |
Warm-up time at start-up | 90 min |
Output | RS 485 Modbus RTU, 4-20 mA |
Pressure | PN 6 ... PN 40 |
Dimension of the sensor | DN 50, DN 80, DN 100 or DN 125 |
Overall dimension of the electric unit | 255 x 170 x 60 mm |
Protection class (sensor) | IP67 |
Protection class (electric unit) | IP66 (explosion-proof) |
mass |
|
