High Pressure Mechanical Ceramic Sleeve
- SHANGHAI
- T/T Credit Card
You May Like
Product Details
| Place of Origin | Jiangsu, China | Type | Ceramic Rods | |
| Application | Industrial Ceramic | |||
| Model Number | 22*36*12MM | Brand Name | Everbest |
Product Description
Specifications
Mechanical ceramic sleeve1.Material:99 Alumina
2.Abrasion resistance
3.Precision
4,anti-corrosion
High pressure mechanical ceramic sleeve.
Feature
Mechanical ceramic sleeve with precision tolerance ,which has the advantages of high wear-resisting,good corrosion resistance , high intensity , precision process, good smoothness, polishing surface and so on.It widelly used in a variety of mechanical field.
Forming methods includes
1,Drying pressing
2,Isostatic pressing
3,Hot pressing casting
Property of alumina.
1. high working temperature
2.high wear resistance
3.good corrosion resistance,
4.high intensity, good smoothness, polishing surface
Items | Unit | 95%Al2O3 | 99.5%Al2O3 |
Density | g/cm3 | 3.7 | 3.9 |
Flexural Strength | MPa | 313 | 340 |
Compressive Strength | MPa | 3400 | 3600 |
Modulus of Elasticity | GPa | 350 | 380 |
Impact Resistance | MPa·m1/2 | 4 | 5.1 |
Weibull Modulus | m | 10 | 10 |
Vickers Hardness | HV0.5 | 1800 | 1900 |
Thermal Conductivity | W/mk | 24 | 27 |
Highest Application Temperature | °C | 1600 | 1750 |
Volume Resistivity at 20°C | Ω.cm20 | >1014 | >1014 |
Dielertric strength | KV/mm | 20 | 25 |
Thermal expansion | X10-6/K | 5.0-8.3 | 5.4-8.3 |
More about us.
Suzhou Everbest engineering ceramic Co.,LTD,which is specialized in designing and manufacturing structure ceramic products and related parts. which has more than 14 years experience in ceramic structures.
We can provide ceramic plunger or ceramic sleeve
with diameter from 2 to 100mm,
the length from 1mm to 500mm.
the tolerance can reached -0.005mm.
Remarks
Shaped as customers' requirment and drawing.If you are interested in our products, please don't hesitate to contact with us,we will reply to you at the first time and provide our the best price,the highest quality,the fastest delivery and the best professional service to you.
