SWR/SNR EXTERNAL & INTERNAL threading tools
- Zhuzhou
- Credit Card
You May Like
Product Details
| Place of Origin | Hunan, China | Brand Name | SANT | |
| Model Number | complete |
Product Description
Specifications
EXTERNAL & INTERNAL threading tools:1.External and internal threading tools
2.SWR/L,SNR/L
3.Threading tool
4.Ni & black.
1.accept special request
2.Resonable price
3.High stability
4.100% quality guarantee
Our threading tools can matching ZCCCT, Israel brand insert
also can supply the inserts to matching our toolholder,such as :ZCCCT,KORLOY,MITSUBISHI,TOSHIBA,CERATIZIT,TaeguTec
type | Dimension | insert | |||||
a | h | b | l | s | |||
SWR/L | 1010H11 | 10 | 10 | 10 | 100 | 16 | R/L11.01W-**GM |
1212H11 | 12 | 12 | 12 | 100 | 16 | ||
1616H16 | 16 | 16 | 16 | 100 | 20 | R/L16.01W-**GM | |
2020K16 | 20 | 20 | 20 | 125 | 25 | ||
2525M16 | 25 | 25 | 25 | 150 | 32 | ||
3225P16 | 32 | 32 | 25 | 170 | 32 | ||
3232P16 | 32 | 32 | 32 | 170 | 40 | ||
2525M22 | 25 | 25 | 25 | 150 | 32 | R/L22.01W-**GM | |
3225P22 | 32 | 32 | 25 | 170 | 32 | ||
3232P22 | 32 | 32 | 32 | 170 | 40 | ||
Type | Dimension | Applicated insert |
SNL0010K11 | d=10,L=125,b=12.5,Dmin=12,s=6,h=9.5,L1=32 | LT11.01N- GM |
SNL0012K11 | d=12,L=125,b=12.5,Dmin=16,s=6,h=11.5,L1=32 | |
SNL0013M16 | d=13,L=150,b=15,Dmin=16,s=10,h=15.5,L1=32 | LT16.01N- GM |
SNL0016M16 | d=16,L=150,b=15,Dmin=20,s=12,h=15.5,L1=45 | |
SNL0020Q16 | d=20,L=180,b=18,Dmin=25,s=14,h=19.5,L1=40 | |
SNL0025R16 | d=25,L=200,b=20,Dmin=30,s=16,h=24,L1=45 | |
SNR0010K11 | d=10,L=125,b=12.5,Dmin=15,s=6,h=9.5,L1=32 | RT11.01N- GM |
SNR0012K11 | d=12,L=125,b=12.5,Dmin=16,s=6,h=11.5,L1=32 | |
SNR0013M16 | d=16,L=150,b=15,Dmin=16,s=10,h=15.5,L1=32 | RT16.01N- GM |
SNR0016M16 | d=16,L=150,b=15,Dmin=20,s=12,h=15.5,L1=45 | |
SNR0020Q16 | d=20,L=180,b=18,Dmin=25,s=14,h=19.5,L1=40 | |
SNR0025R16 | d=25,L=200,b=25,Dmin=30,s=14,h=24,L1=45 |
Production process(with pictures):
1. unprocessed materials
2.Finish machining sipe(the tolerance of height of center to be ±0.02mm.
3.Hear treatment(HRC43-47)
4.Sand blast
5.Black or Ni coating
6Marking & testing
7.Assemble(doing quality test at te same time)
Contact Us
- Zhuzhou Sant Cutting Tools Co., Ltd.
- Contact namecutting tools SANT Chat Now
- Phone86-731-28822550
- AddressNo. 101, Building A2, High-Tech Standard Plant, Liyu Industrial Park, Huanghe North Extension Rd., Tianyuan District, Zhuzhou, Hunan
Product Categories
| all tools | carbide inserts | cutting blade | cutting tools |
| drilling tool | grooving tools | milling tool | New Products |
| spare part | threading tools |
New Products
-
low price threading tool SANT
-
CNC Lathe Turning Tool Indexable External Threading Carbide Tool
-
Stable Performance Flow Cutting Edge Threading Tool Holder with Carbide Inserts
-
machine tools for indexable lathe threading tool
-
CNC Carbide Internal Threading tools
-
SANT carbide threading tool
-
Zhuzhou CNC Threading tools
-
Threading Toolholder
-
Carbide lath threading tool
-
SANT Threading tool(S type)
-
SANT CNC Threading tools
-
Internal Threading Toolholder SNR0010K11
