Home > Products > Touch Screen Kiosk > Discount 55 inch lcd screen player multi touch screen kiosk

Discount 55 inch lcd screen player multi touch screen kiosk

FOB Price

USD $500 - $3,000 / Set

1 Set(Min.Order)

Port GuangZhou
Payment TermsT/T L/C D/P D/A Credit Card PayPal

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Place of Origin	Guangdong, China	Brand Name	HBM
Model Number	HBM-SDS4201	Type	TFT
Application	Indoor	Panel Size	42-65 inch
Max Resolution	1920*1080	Viewing Angle	178
Pixel Pitch	0.264mm (H) x 0.264mm (W)	Color	16.7m
Contrast Ratio	10000:1	Brightness	500cd/m2
Response Time	8ms	Input Voltage	110-240v

Product Description

Discount 55 inch lcd screen player multi touch screen kiosk

Product Description

Specification for Floor standing
Model(inch)	42"	46"	55"	65"
LED	SAMSUNG/LG/AUO LED-TFT	SAMSUNG/LG/AUO LED-TFT	SAMSUNG/LG/AUO LED-TFT	SAMSUNG/LG/AUO LED-TFT
Display Proportion	16:09	16:9	16:9	16:9
Display Area	930*523mm	1018*572mm	1209*680mm	1428*804mm
Resolution	1920*1080	1920*1080	1920*1080	1920*1080
Viewing Angle	178°	178°	178°	178°
Brightness	500cd/M2	450cd/M2	450cd/M2	450cd/M2
Contrast	4000:1	4000:1	3500:1	3500:1
Color	16.7m	16.7m	16.7m	16.7m
Backlight Life	60000h	60000h	60000h	60000h
Voltage	110-240	110-240	110-240	110-240
Power	200W	210W	220W	350W
Play Supports	U Disk/SD-card/CF	U Disk/SD-card/CF	U Disk/SD-card/CF	U Disk/SD-card/CF
Memory Slot	USB2.0HV/SD	USB2.0HV/SD	USB2.0HV/SD	USB2.0HV/SD
Body Meterial	ALU Alloy coverd by Metal(Silvery)	ALU Alloy coverd by Metal(Silvery)	ALU Alloy coverd by Metal(Silvery)	ALU Alloy coverd by Metal(Silvery)
Protect Decoration	Tempered Glass(5mm)	Tempered Glass(5mm)	Tempered Glass(5mm)	Tempered Glass(5mm)
Shell Size	182064070mm	180070090mm	190080590mm	2115932.590mm
Packing Size	1960225810MM	1960225850MM	20302501000MM	22001130250mm
Net Weight	55kgs	60.5kgs	75kgs	85kgs
Gross Weight	65kgs	71kgs	87kgs	100kgs

Main Features

1. Ultra-high-fidelity sound, pleasant stereo sound
2. Ultrathin and ultra-light hardware case, delicate and beautiful
3. Industrial grade paint technology, smooth and uniform, waterproof and dustproof, anti dust and mill!
4. Verity and complete software, stable and reliable
5. Have a lock, anti-theft functions
6. Widely used in the bus, building and lift room, supermarket, pubic places, train etc

Panel Parameter	Panel Size		42/46/55/65 inch (16:9)
	Active Area		1209mm (H) x 680mm (V)(42'')
	Brand for LCD Panel		Full new LG/Samsung A grade
	Max. Brightness		500cd/m²,700cd/m2 is optional
	Max. Resolution		1920 x 1080
	Contrast Ratio		4000:1
	Panel Life		50000hours
	Responsive Time		8ms
	Dot Pitch		0.630mm (H) x 0.630mm (W)
	Viewing Angle		H178/V178
Mini-PC Configuration	CPU		Inter I 3 core 3.2G
	Thread number		4pieces
	Main board		Topstar H61/ASUS H61
	RAM pattern		DDR3 support dual channel DDR3 1333MHz RAM,2GB
	Pattern of channel		Dual Channel
	RAM Slot		2 DDR3 DIMM
	Frequency of RAM		DDR3 1333MHz, DDR3 1333MHz
	Hard Disk		S-ATAII 320GB/500GB/16MB/7200rounds/s
	Capacity of RAM		standard 2GB,4GB, 8GB optional
	Wireless Network card		Atheros AR9285 802.11b/g/n
Touch Panel Parameter	Touch Max Resolution		4096×4096
	Transparency		> 90%, Up to 100%
	Scanning Speed		>50Scans/S
	Response Speed		<12ms
	Touch precision		0.625mm
	Minimum Touch		5mm
	Operation Syst		WINDOWS7
	Altitude		3000m
	Communication		RS-232 Interface Port, USB Port
	Vandal-Proof		Steel Ball (Diameter 63.5mm 1040g Weight) drop from 1040mm, No break
Interface(I/O)	Build in 2.1USB port, HDMI+VGA+AV port.CF/SD card is optional.
Power Supply	AC 110V-240V, 50HZ/60HZ
Product Features	Main Function	Playing file automatically
		With USB update
		Support HD video, pictures and music
		Security and password protection, anti-thief design
		Set up time on/off
		Support Remote controller
		Support Safety lock system
	Support Media Format	MPEG1/2/4, AVI, RM, WMV, DAT, JPEG, BMP, PPT, WORD, EXCEL, TXT, MP3, RMVB, SWF etc.
	Temperature	Storage:-20 Celsius degree to 70 Celsius degree Working: 0 Celsius degree to 70 Celsius degree
	Fixing Method	Floor standing
	Color	Black color with silver side frame,Gold color and other color customized
	Housing Material	5mm thickness tempered glass as LCD/LED panel protection layer
Applicable field	Supermarket, Hotel, Mall center, Shop, Commercial buildings etc.
Packing information	Packaging Size (mm)	1960810225mm(42'')
	Shell Size(mm)	184663460mm (42'')
	Display Size(mm)	930*523mm (42'')
	N.W. / G. W. (kg)	60kg/ 71kg (42'')
	Packing Material	Very strong Honeycomb carton

Detailed functions

Video format

MPEG1/MPEG2/MPEG4/DivX/ASP/WMV/AVI

Audio format

Wave/MP3/WMA/AAC

Image format

JPEG/BMP/TIFF/PNG/GIF

Image resolution

480P/720P/1080P

Payment terms

Sample Leading time					3~5 working days
Bulk Order Leading time					7-10 working days
Payment term					T/T---100% payment before production for sample,30% payment before production and 70% balance before shipping for bulk order.
Warranty					1year
Transportation way					By Express, by air, by sea

Detail pictures

Packaging & Shipping

Advantages

Our advantages:

1.Most and warmly welcome to visit our factory.We can pick you up if hotel clost to our factory in GuangZhou.

2.Convenient to our factory. Metro to Guangzhou PanYu DaShi Exit A .

3.All goods will check by our QC or your QC before delivery.

4.Our factory mainly produce led light box, advertising display, acrylic crafts and advertising screws.With many years experience in this line ,we can supply professional recommend and high quality to every of our client.

5.All kind of goods can supply installation video or production video.
