CH10--CH200 Type Mixer
- Shanghai China
- Credit Card
You May Like
Product Details
| Place of Origin | Shanghai, China | Brand Name | Minhua | |
| Model Number | CH10--CH200 | Type | Mixing Machine |
Product Description
Specifications
1.Pharmaceutical Mixer2.It is easy to clean
CH10--CH200 Trough type mixing machine is designed for thoroughly mixing powders or pastes. It is a horizontal trough type mixer with single stirring arm. The stirring arm is removable so that is easy to clean. The part is surfaces which may touch the mixing materials are made of stainless steel, So they are good corrosion - resistant ,the mixing trough can automatically reverse for discharge and the missing time can be automatically controlled.
CH10A--CH200A Trough type mixing machine is designed on the base of the former CH10--CH200. The configuration employ stainless steel that is easy to clean and maintaining and meet GMP standard
ITEM | TYPE |
| |||||||||||||
CH10 | CH50 | CH100 | CH150 CH200 |
| |||||||||||
Trough capacity L | 10 | 50 | 100 | 150 200 |
| ||||||||||
Mixing arm speed r/min | 25 | 24 | 24 | 24 24 |
| ||||||||||
Mixing periods | 5~20 | 5~20 | 5~20 | 5~20 |
| ||||||||||
Main motor kw | Y06324 0.25KW | Y90S-4 1.1KW | Y100L1-4 2.2KW | Y100L-4 3KW Y112L-4 4KW |
| ||||||||||
Tilting motor kw | Hand | Y802-6 0.75KW | Y802-6 0.75KW | Y802-6 0.75KW |
| ||||||||||
Overall dimensions mm | 600×280×450 | 920×420×820 | 1100×440×900 | 1400x600x1100 1400x600x1200 |
| ||||||||||
B type size | 600×280×500 | 920×420×820 | 1100×440×900 | 1370x650x1100 1370 x 650x1100 |
| ||||||||||
Weight kg | 40 | 200 | 250 | 750 800 |
| ||||||||||
| Specification | CH-100 | CH-150 | CH-200 | CH-400 | CH-600 | |||||||||
| Working volume (L ) | 100 | 150 | 200 | 400 | 600 | |||||||||
| Motor power (Kw) | 2.2 | 3 | 4 | 5.5 | 11 | |||||||||
| Stirring rotating speed (r/min) | 24 | |||||||||||||
| Feeding angle(degree) | 105 | 105 | 105 | 105 | 105 | |||||||||
| Weight kg | 400 | 500 | 6 | 700 | 900 | |||||||||
| Overall dimension mm | 1400x580x1000 | 1600x600x1050 | 1870x650x1065 | 1400 x 750 x 1100 | 2600x 800 x 120 | |||||||||
