Home > Products > Granulators > FZ Crush and Granulator Machine
FZ Crush and Granulator Machine
- shanghai
- D/P D/A Credit Card
You May Like
Product Details
| Place of Origin | Shanghai, China | Brand Name | MINHUA | |
| Model Number | FZ | Application | Other, crush and granulator machine | |
| Type | Other, Granulator, Granulator |
Product Description
Specifications
FZ crush and granulator machineDescriptions
This machine applied to Pharmaceutical ,food ,fine chemical industries. Cover GMP standard, all the machine made by stainless steel.
After the material into the feeder container. Drop to subulate working station. The revolving circumgyrate parts eddy the material move. centrifugal effect make the material to the mesh surface. Same time the circumgyrate part revolving cut the material ,the material leak after cut and mesh. The diameter of material decide by the mesh.
Features
Complete resolve the difficulty of swimming granulator mesh wear and tear freely .and the Chipping pollute the material.
Special axes pressurize design ,guarantee lube no leak.
Control the granulator freely.
No stock dead angle, avoid the material superheat.
Low dust ,no shake and low noise.
High efficient and save source, product capacity is high.
Shape is beautiful and clean freely.
Pharmaceutical material crush
--wet material granulator
--dry material granulator
-- incompetent tablet ,need callback ,can granulator base grain diameter
request
food: biscuit callback and use.
Others: thick material crush and granulator
Nubbly material crush and granulator
Technical Parameters
No | Itemtype | FZ-150 | FZ-300 | FZ-450 | FZ-700 |
1 | product capacity(kg/h) | 15-150 | 30-300 | 45-450 | 70-700 |
2 | grain(mesh) | 6-80 | |||
3 | Driver temperature() | 30 | |||
4 | Timing size(r/min) | FZ is single speed 2840 | |||
5 | Motor power (kw) | 0.75 | 1.5 | 2.2 | 4 |
6 | Overall size(L×W×H) | 820×425×1360 | 900×425×1380 | 900×425×1460 | 1200×580×1800 |
7 | Output station high to floor | 650 | 650 | 650 | 650 |
