Thin Blade Longitudinal Cutting Line Pressing Carton Machine
- shanghai
- T/T
You May Like
-
Thin Blade Cutting&creasing Machine ,machine to Make Cardboard Box
-
Automatic Carton Slitter Scorer Machine / Corrugated Box
-
Carton Box Making Machine ,thin Blade Slitter Scorer Machine
-
Corrugated Cardboard Thin Blade Slitter Scorer/carton Box Manufacturing Machine
-
High Speed Absorption Feeding Printing Grooving Die-cutting Machine
-
Automatic Computerized Printer Slotter Die-cutter Machine
Product Details
| Condition | New | Application | Commodity | |
| Packaging Type | Cartons | Packaging Material | Paper | |
| Automatic Grade | Automatic | Driven Type | Electric | |
| Power | 3-4kw | Place of Origin | Shanghai, China | |
| Brand Name | Qisheng | Model Number | SBF Series | |
| After-sales Service Provided | Engineers available to service machinery overseas |
Product Description
Specifications
1.Thin blade longitudinal cutting line pressing carton machine2.selling well more than 20 countries
Thin blade longitudinal cutting line pressing carton machine
Functions:
Mark of main being used in carboard paper and line ball.
Features:
The machine is driven by stepless motor and its power is transmitted synchronically with gears and sprocket wheels. It is featured with low noise, smooth drive and easy adjustment of breadth. The paper separating blade is made of 1.2mm high-strength alloy and feeding rollers are made of rubber that leave no marks on paper. The machine is error-free in paper separating and good at saving electricity with lower rate. Equipped with auto and manual blade milling unit, the machine can ensure smooth edges of the paper and non shrunken corrugations and is recongized as the ideal equipment for carbon box and packing industries.
Main Technological parameters
Model(Unit:mm) | SBF2200 | SBF2500 | SBF2800 |
Breadth | 2200 | 2500 | 2800 |
Maximum feeding size | 2100 | 2400 | 2700 |
Minimum feeding size | 120 | 120 | 120 |
Maximum blade diameter | 260 | 260 | 260 |
Minimum blade diameter | 225 | 225 | 225 |
Motor power rate | 3 | 4 | 4 |
Trace pressing wheels | 4 | 6 | 6 |
Paper separeting blades | 3 | 4 | 4 |
