Best maquina para sublimar camisetas
- 10 Set / Sets per Month
- Qingdao port
- T/T
You May Like
Product Details
Condition | New | Type | Turning Center | |
CNC or Not | Normal | Automatic Grade | Semi-Automatic | |
Max. Swing Diameter | 130:770 | Place of Origin | Shandong, China | |
Brand Name | haige | Model Number | WXC30S | |
Voltage | 380V/440V | Power(W) | 56KW | |
Dimension(L*W*H) | 12.5mX2.2mX1.5m | Weight | 6T | |
Certification | ISO9001 | After-sales Service Provided | Engineers available to service machinery overseas |
Product Description
Best maquina para sublimar camisetas
Specification | WXC30S | |
RAW | Diameter Range(mm) | Φ6˜Φ32 |
Raw Material Length(mm) | ≥1400 | |
Tensile Strength (M pa) | ≤1100 | |
Surface Hardness | ≤HB320 | |
Curvature(mm/m) | ≤1.5 | |
Diameter Tolerance | according to GB 702-88 second group | |
Roundness | ≤50% of the diameter tolerance | |
Surface Roughness(Ra) | ≤25˜50um | |
FINISHED | Diameter Range | Φ5.5˜Φ30 |
Unilateral Cutting Depth(mm) | 0.2-1 | |
Diameter Tolerance | ≤IT9(standard tolerance grade) | |
Surface Roughness(Ra) | ≤6.3μm | |
Roundness | ≤0.03 | |
Feeding Cutting Speed(m/min) | 1.0~10.0(for continuous chips and high strength and hardness should reduce the speed | |
Cutter Head Rotational Speed(rpm) | 450˜1250 | |
Main Machine Motor Power(KW) | 45 (4 Poles) | |
Auxiliary Machine Motor Power(KW) | 4(feeding part)+0.55((discharging part) 4 Poles | |
Main Machine Outline Dimensions (Length*Width*Height) m | 2.5mX2.2mX1.5m (for your reference) | |
Full Set Machine Outline Dimensions (including auxiliary machine) (Length*Width*Height) m | 12.5mX2.2mX1.5m (for your reference) | |
Main Machine Weight | 3.5(6.0) | |
Total Capacity (KW) | 56 | |
Compressed Air Source(user prepare by themselves) | 0.5~0.8MPa,1.8m3/min,more than 0.8 m3 gasholder, two-stage oil-water separator and compressed air freezing drier |
1. Green, with no environmental harm.
2. Surface of finished goods possesses better brightness.
3. Faster turning and straightening, and higher working efficiency.
4. Have unique advantages in processing over-long bars
(including infinitely long coiled raw materials).
5. Operation is simple, reducing labor cost and enhancing profit.
6. All of the metal shavings of turning can be recycled and resold,
reducing cost and enhancing profit once again.
practical; stable processing; highly speed; high efficiency; better surface quality. Online adjusting tool holders. Full-automatic online loop-locked control of material diameter can be achieved if more control points are added. The whole line of the equipment owns high degree of automation. Turning speed of materials can reach 1-12m/min. The equipment possesses automatic and manual control systems, and the two systems can be interlocked in usage.
New-generation products of centerless lathe series independently developed by Yantai Haige Machine Tools Co., Ltd are mainly used for the skin processing of long and round metal materials, including round steel (tubing) etc. They can rapidly wipe off the defects of bars, such as surface crack, oxide layer and decarburized layer. Furthermore, they can produce high-quality bar, tubing, and wire rod of metal brightness with high precision and surface roundness. The efficiency is several times to more than ten times superior to conventional craft, greatly reducing numbers of workers and equipment cost.
