horizontal CNC lathe machine--WXC80S

Specification

WXC80S

RAW
   MATERIALS

Diameter Range(mm)

Φ21~Φ85

Raw Material Length(mm)

≥2200

Tensile Strength (M pa)

≤1100

Surface Hardness

≤HB320

Curvature(mm/m)

≤1.50

Diameter Tolerance

According to GB 702-88 second group

Roundness

≤50% of the diameter tolerance

Surface Roughness(Ra)

≤25~50μm

FINISHED
GOODS

Diameter Range

Φ20~Φ80

Unilateral Cutting Depth (mm)

0.35~1.50

Diameter Tolerance

≤IT9 (standard tolerance grade)

Surface Roughness(Ra)

≤3.2μm

Roundness

≤0.03mm

Feeding Cutting Speed(m/min)

1.0-10.0(for continuous chips and high strength and hardness should reduce the speed)

Cutter Head Rotational Speed(rpm)

290~800 (Six Poles) 430~1200(Four Poles)

Main Machine Motor Power(KW)

75

Auxiliary Machine Motor Power(KW)

5.5(feeding part)+0.75(discharging part)

Main Machine Outline Dimensions

(Length*Width*Height) m

3.5m X 3.5m X 2.4m ( for your reference)

Full Set Machine Outline Dimensions

(including auxiliary machine)

(Length*Width*Height) m

15.5m X 5.0m X 2.4m ( for your reference)

Main Machine Weight
(including auxiliary weight) (T)

8.5 (11.5) ( for your reference)

Total Capacity(KW)

95

Compressed Air Source

(user prepare by themselves)

0.5-0.8Mpa,1.8m³/min,0.8m³ gasholder,two-stage oil-water separator and compressed air freezing drier
