skiving roller burnishing machine for cylinder manufacturer in China
- Qingdao
You May Like
-
Best skiving roller burnishing tool suppliers in China
-
CNC stainless steel cylinder polishing machine for sale
-
CNC stainless steel cylinder polishing machine made in China
-
skiving roller burnishing machine
-
cnc skiving & roller burnishing machine for round bar excircle cleaness
-
cnc roller burnishing machine manufacturer
Product Details
| Condition | New | Place of Origin | Shandong, China | |
| Brand Name | Haige | Model Number | ZTG2590 | |
| CNC or Not | CNC | Voltage | 220V | |
| Weight | 15t | Dimension(L*W*H) | 25400*3600*2200(mm) | |
| Power(W) | 100KW | Certification | Iso9001 | |
| Warranty | 1 year | After-sales Service Provided | Engineers available to service machinery overseas |
Product Description
We can provide CNC Skiving & Roller Burnishing Machines with different configurations that can process work pieces with inner diameters from Ø40 to Ø250 and the lengths of 1.5m, 2m, 3m, 4m, 6m, 9m, and 10m, among others.
Field of Application
Contruction machinery, colliery hydraulic holder, colliery scaper conveyor, special usage truck, maritime ship, harbour machinery, petroleum machinery, mining machinery, water conservancy machinery etc.
Main Parameters | ||||
Model | ZTG2530 | ZTG2560 | ZTG2590 | |
Workpiece dimension | Internal diameter(mm) | Φ50-250
| Φ80-250
| Φ90-250
|
External diameter(mm) | Φ60-300
| Φ90-300
| Φ100-300
| |
Processing length(mm) | 500-3000 | 1200-3000 | 1650-9000 | |
Speed | Spindle speed(r/min) | 50-1500 | ||
Locating seat movement(mm/min) | 6000 | |||
Spindle box movement(mm/min) | 8000 | |||
Motor power | Spindle servo(Kw) | 37/56 | ||
Feed servo(Kw) | 6 | |||
Cooling system | Oil tank capacity | 4150+1850 | 4150+1850 | 6000+1850 |
Pumping capacity | >500 | >500 | >700 | |
Filter fineness | 50 | |||
Total motor power | 90 | 100 | ||
Dimension | 12100*3600*2200 | 18820*3600*2200 | 25400*3600*2200 | |
CNC system | Spanish:FAGOR, Germany:SIEMENS | |||
Advantages compared with traditional honing
1) Improve processing efficiency: Processing speed is nearly 20 times that of honing.
2) Enhance surface hardness: Surface hardness is increased by more than 50%.
3) Processing precision: Processing precision can reach level IT8, and surface roughness can reach Ra0.05-0.4μm.
4) Working environment: Low noise, non-pollution, labor cost-saving.
5) Reasonable processing arrangement: Skiving & roller burnishing can be arranged as the last operation after the others (such as drilling oil filler hole, welding, threading).
A. Warranty period: 1 year,except for fast-wearing parts
B. Reply your enquiry in 24 working hours
C.Customized design is available. OEM& ODM are welcomed.
D. If necessary,we can dispatch our well-trained and professional engineers to our customers' factory to help them install and debug the equipment.
E.Special discount can be provided to our distributor.
Yantai Haige Machine Tools Co., Ltd is a professional company in
manufacturing of *Round metal bar peeling machine
(used to quickly remove the rusted layer, cracks and other defects from the surface of the round black bars)
*Round metal bar straightening machine
(used to straighten and calender the metal bars after peeling)
*Skiving roller burnishing machine
(used to process the inner wall of the cylinder or the metal tube/Pipe)
*Piston rod polishing machine
(used to polish the piston rod before and after plating
