100% Manufacturer Ce-certified Battery Operated Wireless Backup Camera with Quad Monitor
- Guangzhou
- Credit Card PayPal
You May Like
-
100% Manufacturer Ce-certified DC 10-48V Max 128G Recording 7 Inch 2.4G Digital Wireless Monitor with 4 Channel
-
100% Manufacturer Ce-certified DC 12-32V Night Vision 2.4G Digital Wireless Forklift Camera System for Forklift Truck Trailer
-
100% Manufacturer DC 12-32V Night Vision 2.4G Digital Wireless Camera + 2.4G Digital Wireless Receiver for Truck Trailer
-
100% Manufacturer Ce-certified DC 12-32V Night Vision 2.4G Digital Wireless Horse Trailer Camera System with 7 Inch Monitor
-
100% Manufacturer Ce-certified DC 12-32V CMOS 700tvl Waterproof 2.4G Digital Truck Trailer Camera System
-
2.4G Digital Wireless 7inch Reversing Camera System Built-in Wireless TX Backup Camera for Trailer 20pcs White Lights Option
Product Details
Type | Other, Reverse Camera, Battery Operated Wireless Backup Camera | Voltage | Other, DC12-32V | |
Power | Max 5W, 12-32V | Car Make | All | |
Place of Origin | Guangdong, China | Brand Name | OEM/ODM | |
Model Number | MCB0137a | Warranty | 12 Months |
Product Description
100% Manufacturer Ce-certified Battery Operated Wireless Backup Camera with Quad Monitor
Application :
Front ,Side ,Back View Monitoring for all vehicles
Key Spec :
Monitor | Camera | ||
Model | M02104CH | Model | C09158AI |
LCD size | 7" | Image Device | 1/3" CMOS |
Resolution | 800 x 3 (RGB) x 480 | TV System | PAL & NTSC Adjustable |
Contrast | 500:01:00 | Array Size | 728*488 |
Brightness | 400 cd/m² | Sensing Area | 4.6228 mm (H) ×3.6112 mm (V) |
Viewing Angle | U: 50 / D: 70, R/L: 70 | Scan Mode | Progressive |
Aspect Ratio | 16:09 | Sync. System | Internal |
Channel | 4 channels | Resolution | 700 TV Lines |
Operating Frequency | 2400 - 2483.5 MHz | Minimum Illumination | 0.1 Lux (day), 0 Lux (with IR) |
Transmitting Distance | 30-120 M | Microphone | Yes |
Recieving Sensitivity | -89 dBm | Electronic Exposure | Up to 510:1 |
Decompression Form | MPEG4 | AGC | Auto |
Emitting Frequency | 17 dBm | S/N Ratio | Better than 48 dB |
Modulation | 2.4G FSK/GFSK | White Balance | Auto |
TF Card | Max. 128G | Electronic Exposure | Up to 510:1 |
Time Delay | 120ms | BLC | Auto |
System Format | PAL & NTSC Adjustable | Current Consumption | Max. 220 mA/12V |
Power Consumption | Max. 6W | Power Supply | DC 12-32 V |
Loudspeaker | 1.5W/8Ohm | Operating frequency | 2400 -2483.5 MHz |
Operating Temperature | -20~+70ºC, RH 90% | Transmitting distance | 30-120M |
Storage Temperature | -30~+80℃, RH 90% | Transmitting speed | 12Mbps |
Power Supply | 10-32V | Decompression form | MPEG4 |
Transmit output power | 17 dBm | ||
Lens | f = 2.8mm | ||
Lens Angle | 120° | ||
Operating Temperature | -20°C~60°C, RH 90% MAX. | ||
Storage Temperature | -30°C~80°C, RH 90% MAX. | ||
Mirror or Normal | Adjustable in Monitor Menu |
Battery | ||
Nominal voltage | 12V | |
Rated Capacity | 2600mAh | |
Overcharging protection voltage | 12.5V ± 0.25V | |
Voltage discharging protection | 10.5V ± 0.25V | |
Charging Mode | Constant current | |
Maximum charging voltage | 12.60-12.90V | |
Charge Current | 0.7-1.5A | |
Charging temperature | 0~45℃,45~85%RH | |
Discharging temperature | -20~55℃,45~85%RH | |
Storage temperature and humidity range | Short-term: more than a month -20~+55℃,45~85%RH | |
Interim: more than three months -20~+45℃,45~85%RH | ||
Long-term: one year or less -5~+20℃,45~85%RH |
