HXE-24DW High speed fine copper wire drawing machine
- Shanghai
- T/T
You May Like
-
fine wire drawing machine Competitive price small wire drawing machine china factory making cable equipment
-
Fine copper wire producing machine -horizontal type
-
High speed medium &fine Electric wire cable producing machine
-
fine wire producing machine/cable machine-high quality &efficient-24DW
-
22DS-Fine Wire & cable Drawing Usage Machine-china
-
continuous pulling machine for cable making
Product Details
| Place of Origin | Jiangsu, China | Brand Name | HXE | |
| Model Number | 24DW | Usage | Drawing |
Product Description
HXE-24DW High speed fine copper wire drawing machine
HXE-24DW Fine copper wire drawing machine is used to draw single bare copper wire from 0.6mm -1.2mm to 0.08mm-0.5mm.
I.Components
Name | Quantity |
1.Pay-off stands | 1 set |
2.HXE-24DW main drawing machine | 1 set |
3.Spare parts |
II.Main Technical parameters
1.Usage: copper drawing
2.Inlet size: 0.6mm —1.2mm
3.Outlet size: 0.08mm—0.5mm
4.Drawing speed: 2500 MPM/ MAX.
5.Die No: 24 pcs(customer self provides) Die size:Φ25mm×8
6.Reduction ratio of machine: from1st~23st:15%, 24nd: 8%.
7.Wire drawing type: horizontal and continuous and sliping drawing
8.Main motor: 20HP(15KW)AC motor,controlled by inverter
Spool motor: 5HP(3.7KW) AC motor, controlled by inverter
9.Machine body: cast iron
10.Machine transmission: by falt belt
11.Capstan: ceramic coated
12.Lubricating: sparying above dies and capstans. requiring lubrication capactiy 40L/min
The end
Manufacture Suzhou Hengxie Machinery Co., Ltd
Sign and Charge Only by Bryant Wu
Date 2015-10-07
