Low Price Color Optional Mechanical Punch Machine 20ton Leather Press Machine

A. The Machine of Whole structure and Characteristics:

JB23 Series Presses is one of the new generation of plate process and developed by our company, The press is for cutting, punching, blanking, bending and light stretching work.

1. C- frame provides maximum rigidity and minimum deflection for accurate parts and long tool life. Steel-welded frame, high rigidity and less deformation Compact. Thick plates and large columns provide you with the stable platform you need for your demanding application.

2. Wide body frame eliminating vibration for improved ide life and machine, which means economical and practical. Operation space is wide, and the movable bolster could be moved out of frame to set the die. The structure is simple beautiful.

3. High accuracy, high efficiency, simple and convenient operation, good performance, favorable price and best service.

B. Transmission control and brake systems:

1. Use the combine of dry friction clutch and brake pneumatic, rigid inter locking, reliable piece of friction material semi-metallic friction material SMFM-88,less pollution, long life. With the transfer torque, rotational inertia is small, smooth transmission, flexible operation, convenient of installation and maintenance.

2. Die height adjustment of slider with manual mode, the scale display. Extended by four triangular rail, easy adjustment.

3. Use double safety valve to ensure the accurate implementation of the clutch instruction.

4. Electrical control is installed PLC, 8 group cam controller, reliable action.

5. Electrical control adopts Omron PLC for centralized control, improved machine reliability.

6. Proximity switch with 8 groups consisting of Schneider cam controller, reliable synchronization detection and monitoring.

7. Machine is with both hands button and foot switch to achieve continuous, single and inching practices.

8. Can move the ram up slowly, which allows the operator to control Mold adjustment conveniently.

C. Ram adjustment and Structure:

1.Adjustable stroke machine, slide stroke to achieve a certain level within the range of adjustable, body steel plate welded structure, the whole body is tempered, use the secondary transmission, the transmission part of the crankshaft horizontal Placement, flywheel and gear are the external open style, easy maintenance.

2. Slider is a cast box structure and rigid. Collapse of the slider-style installation of pressure overload protection device, simple structure, if the slider overload, the fuse collapse is damaged, then protect the machine tool and die from damage.

D. Electrical system and the safety interlock:

1. Electrical components are imported or from Sino-foreign joint Venture, in accordance with international standards, reliable safety, long life, good anti-interference ability, a radiation unit is fitted in electrical cabinet.

2. Protective fence and the safety interlock to ensure the operation safety. Have a movable single-hand pedal switch, easy to operate.

Packing & Delivery

Payment terms

• 30% T/T as deposit, and 70% is paied before shipping.
• 100% irrevocable letter of credit (L/C)at sight.

How about your machine quality? We are worry about the quality.

RE: XinLin is a mature brand in CHINA, through our 20 years research in technology,our design including structure and

detailed security and precision has enhanced greatly,and can match all the CE standard or more strict standard. Our machines distribute worldwide to about 50 countries where there are metal plate industry, there are Brillante machines. And any nations use our machines, there are good reputation and terminal user satisfaction.

Whether the machine price can be more discount?

RE:1.We always provide high quality machine, as we know,oversea market is more important and difficult than domestic market because of communication time costing after sales, so our machine follows qaulity standard to make sure the machine can work more than the real warranty period. In this way,we will save a lot and think in advance for the client.

RE:2. we are sure to provide quality=price and price=quality ,the matched price and acceptable for the clients and durable  for our machines.We welcome your negotiate with us and get a good satisfaction.
