GS1008 injection molding machine
- shanghai
- T/T
You May Like
-
plastic moulding machine -china top quality -POYTON brand
-
plastic moulding machine -China top quality -POYTON brand in 2015
-
Shanghai poyton manufacture injection moding machine
-
Poyton- injection molding machine
-
special vacuum package machine for sodium citrate in 2015
-
in 2015 INJECTION MOULDING MACHINE
Product Details
Condition | New | Type | Preform Injection | |
Style | Horizontal | Brand Name | POYTON- injection molding machine sale | |
Model Number | PY- injection molding machine sale | Place of Origin | Shanghai, China | |
Plastic Type | Thermoplastic | Automatic | Yes | |
Injection Weight | series | Injection Rate | series | |
Clamping Force | series | Opening Stroke | series | |
Power(W) | 5kw | Certification | Iso9001 | |
After-sales Service Provided | Engineers available to service machinery overseas |
Product Description
Specifications
1.High speed systerm and Energy-saving GS68V injection molding machine2.High speed systerm
3.Energy-saving
4.short moulding
High speed systerm and Energy-saving GS68V injection
|
|
| GS68V | ||
A | B | C | |||
| Screw Diameter | mm | 26 | 30 | 34 |
Screw L/D Ratio | L/D | 24.2 | 21 | 19.5 | |
Shot size(Theoretical) | cm3 | 66 | 88 | 113 | |
PS) Injection Weight | g | 60 | 80 | 103 | |
PS Injection Rate | g/s | 60 | 80 | 103 | |
PS Plasticizing capacity | g/s | 6.3 | 8.4 | 10.3 | |
Injection Pressure | Mpa | 236 | 177 | 138 | |
Screw Speed | Rpm | 0-260 | |||
| Clamp Tonnage | KN | 600 | ||
Toggle stroke | mm | 270 | |||
Space Between Tie Bars | mm | 3310*310 | |||
Max.Mold Height | mm | 330 | |||
Min.Mold height | mm | 120 | |||
Ejector stroke | mm | 70 | |||
Ejector tonnage | KN | 22 | |||
Ejector Number | piece | 1 | |||
| Max.Pump Pressure | Mpa | 16 | ||
pump motor power | KW | 7.5 | |||
Heater Power | KW | 65.1 | |||
Machine Dimension(L*W*H) | m | 3.77*1.11*1.76 | |||
Machine Weight | t | 2.5 | |||
PS Hopper Capacity | Kg | 25 | |||
Oil Tank Capacity | L | 180 |
Pre-sale service
•Provide relevant advices during project scheduling carrying-out
•Provide initial proposal, process flow diagram, technical documents and equipment layout plan
•Provide engineering cases for reference.
•Provide our documents about logistics management and quality control.
Sale tracking service
We will assign our experienced project manager to do the job as below:
• Sign contract
• Conform drawing
• Equipment fabricating
• Initial assembly commissioning
• Final assembly commissioning
• Ex factory inspection
• Delivery
• Final commissioning
• Inspection and acceptance
After-sale service
•Provide technical support and production line upgrade;
•Feedback within 2h after receive fault notification or service requirement, assign our engineers onsite within 24h,within 48h at the latest;
•Warranty period:1 year after equipment’s acceptance.Service in the warranty time includes: guarantee for repair(whole equipment),guarantee for replace(except easily damaged partsand man-made damage),guarantee for return(optional components)
Poyton had provide the Turnkey solution for Vacuum blood collection tube projects in China, East European,
Russia, Venezuela, Brail, Kazakstan, Iran,Saudi Arabia, India, Africa etc. Zone and countries. Include machine
installation, debugging, production technology transfer, personnel training, raw material test and finished
products test etc,which got the high praise and good reputation by general customers.
