Big Bore Gap-bed Lathe
Negotiable
1 (Min. Order)
You May Like
Product Details
| Condition | New | CNC or Not | Normal | |
| Place of Origin | China | Model Number | 920-2608 |
Product Description
Specifications
*Max. swing diameter :over bed(mm) 660(26") ,over carriage(mm) 420(17") ,over gap(mm)870(34") ,Max.
Big Bore Gap-bed Lathe
| Order No. | 920-2608 | 920-2612 | |
| Max. swing diameter | over bed(mm) | 660(26") | |
| over carriage(mm) | 420(17") | ||
| over gap(mm) | 870(34") | ||
| Max. truned diameter(mm) | 520(20-2/5") | ||
| Max. length of workipiece(mm) | 2000(80") | 3000(118") | |
| Effective length in gap(mm) | 240(9") | ||
| Spindle | Spindle bore(mm) | 105(4") | |
| Taper of bore | 113mm1:20 | ||
| Number of speeds | 12 | ||
| Spindle speed scope(r/min) | 36-1600 | ||
| Thread cutting | 22 Metric Threads | 1-14mm | |
| 25 Inch Threads | 28-2 TPI. | ||
| 24 Diameter Pitch Threads | 56-4D.P | ||
| 18 Module Threads | 0.5-7mm | ||
| Range of feeds | Longitudinal(mm) | 0.063-2.52(0.023"-0.937) | |
| Cross(mm) | 0.027-1.07(0.011"-0.404") | ||
| Rapid traverse | Longitudinal(m/min) | 4.5 | |
| Cross(m/min) | 1.9 | ||
| Max. traver of top slide(mm) | 145(5-3/4") | ||
| Max. travel of cross slide(mm) | 310(12-3/32) | ||
| Max. size of tool(WxH)(mm) | 25x25(1"x1") | ||
| Tailstock sleeve | External diameter | 75(2-61/64") | |
| Taper of bore | M.T.NO.5 | ||
| Max. traverse(mm) | 150(5-29/32") | ||
| Power of main motor(KW) | 7.5(10HP) | ||
| Overall dimensions(LxWxH)(mm) | 3500x1100x1450 | 4500x1100x1450 | |
| Net weigh(kg) | 3000 | 3350 | |
Big Bore Gap-bed Lathe
