Zin Plated Din1142 Wire Rope Clip
- Qingdao/Tao
- T/T L/C D/P D/A Credit Card PayPal
You May Like
Product Details
| Place of Origin | Shandong, China | Brand Name | Sail Rigging | |
| Model Number | Galv Malleable Wire Rope Clamps TYpe A | Usage | Other, Wire Rope Clip | |
| Material | Other, Malleable Iron and Q235 Carbon Steel, Malleable Iron and Q235 Carbon Steel | Structure | G Clamp | |
| Standard or Nonstandard | Standard |
Product Description
Specifications
Galv Malleable Wire Rope Clips DIN 11421.Material:Casting Iron,Q235
2.Size:6-50mm
3.Surface:Electro Galv.
Galv Malleable Wire Rope Clips DIN 1142
1.Material:Casting Iron,Q235
2.Size:6-50mm
3.Surface:Electro Galv.
4.Long service life
Application
Wire Rope Clamps or Wire ROpe Clips are mainly used for temporary connection and fixtion of steel wire ropes.
It is a clampes widely used in lifing operation.
1.Optionals :locknuts,surface treatment,special specifications can be produced according to customers'requirements
2.Commodity Name:DIN1142 malleable wire rope clip
3.Category :Rigging hardware,Rigging
4.Origin :China mainland
5.Other Standard :DIN ,JIS,US
6.Material :stainless steel,carbon steel,
7.Surface :hot dipped galvanized,electro galvanized,self-colored
8.Size :5mm-40mm
9.NW(kg/100pcs) :2.2KG-260KG
10.packing :carton,woven bag or gunny on the pallet or as your requirements
11.Delivery Time :within a month;FOBQingdao
12.payment term :L/C,T/T
13.Supply Ability :150-200ton/month
14.Advantage :about10 years production experience,high quality with competing prices;the perfect after-sales service
DIN1142 malleable wire rope clip
| Size | A | B | C | D | E | F | G | 100/WT |
| mm | kg | |||||||
| 5 | 12 | 13 | 13 | 5 | 13 | 25 | 20 | 2.08 |
| 6.5 | 14 | 16 | 17 | 6 | 14 | 30 | 26 | 4 |
| 8 | 18 | 20 | 20 | 8 | 18 | 39 | 33 | 8.2 |
| 10 | 20 | 20 | 24 | 8 | 21 | 40 | 38 | 9.2 |
| 13 | 17 | 28 | 30 | 12 | 29 | 55 | 52 | 27.5 |
| 16 | 32 | 32 | 35 | 14 | 35 | 64 | 64 | 43 |
| 19 | 36 | 32 | 36 | 14 | 40 | 68 | 69 | 49 |
| 22 | 40 | 34 | 40 | 16 | 44 | 74 | 80 | 68 |
| 26 | 46 | 38 | 50 | 20 | 51 | 84 | 91 | 117 |
| 30 | 54 | 41 | 55 | 20 | 59 | 95 | 107 | 140 |
| 34 | 60 | 45 | 60 | 22 | 67 | 105 | 119 | 213 |
| 40 | 68 | 49 | 65 | 24 | 77 | 117 | 135 | 268 |
