Home > Products > HYDRAULIC PRESS > China Hydraulic Press 200 Ton Manufacturer
China Hydraulic Press 200 Ton Manufacturer
- Shanghai Nantong
- T/T L/C D/P D/A Credit Card PayPal
You May Like
Product Details
| Condition | New | CNC or Not | CNC | |
| Power Source | Hydraulic | Place of Origin | Jiangsu, China | |
| Brand Name | Better | Model Number | Y27 200 | |
| Voltage | 380V | Weight | 7ton | |
| Certification | CE,ISO,TUV | Warranty | 18months | |
| After-sales Service Provided | Engineers available to service machinery overseas |
Product Description
Specifications
China hydraulic press 200 ton manufacturer1.good rigidity and stability
2.high quality
3.low price
China hydraulic press 200 ton manufacturer
Y27 China hydraulic press 200 ton manufacturer performance:
1.Computer optimized design, 4-column structure, which is simple, economic and practical
2.Hydraulic system adopts integrated cartridge valve system, which is reliable, durable and less hydraulic shock, with shorter connection pipeline and fewer releases points.Hydraulic integrated system adopt independen control system.
3. Independent electrical control, reliable,audio-visual and convenien for maintenance.
4. Centralized button control system, with adjustments, hand and semi-auto operation modes at operator's choice.
Y27 China hydraulic press 200 ton manufacturer parameter:
| NO | ITEMS | PARAMETER | UNIT | |
| 1 | Rated force | 2000 | kn | |
| 2 | Return force | 240 | kn | |
| 3 | Ram stroke | 710 | mm | |
| 4 | Max. daylight | 1120 | mm | |
| 5 | Cushion force | 630 | kn | |
| 6 | Cushion return force | 250 | kn | |
| 7 | Cushion stroke | 250 | mm | |
| 8 | Ram speed | Idie stroke | 150 | mm/s |
| Pressing | 5-12 | mm/s | ||
| Return | 95 | mm/s | ||
| 9 | Cushion speed | Knock out | 38 | mm/s |
| Return | 95 | mm/s | ||
| 10 | Table size | L-R | 1000 | mm |
| F-B | 940 | mm | ||
| 11 | Cushion area | L-R | 670 | mm |
| F-B | 670 | mm | ||
| 12 | Outline dimensions | L-R | 3100 | mm |
| F-B | 1350 | mm | ||
| Height above floor | 4000 | mm | ||
| 13 | Motor capacity | 15 | kw | |
If you have any other requirements for the size, pls do not hesitate to contact us, or you can advise us your ideas or thoughts for the machine, we can kindly design for you and communicate with you for the details.
Processing progress:

1.How about your Y27 China hydraulic press 200 ton manufacturer quality?
Better is a mature brand in CHINA,through our many years research in technology. our design including structure and detailed security and precision has enhanced greatly,and can match all the CE standard or more strict standard.Our machines distribute worldwide to about 50 countries where there are metal plate industry ,there are Better machines.
2. What’s your after-sale service?
Better provide oriented after-sales service including the oversea engineers training available and also international dealer center for any emergency guidance.We have established worldwide network to guarantee our timely response for your any demand no matter where are you.
We welcome engineers from your side to learn the technical design and normal maintenance here,this will help your easy in understanding and helpful if you need to be our dealer.
3. How to operate your Y27 China hydraulic press 200 ton manufacturer ?
Don’t worry,we have our company own CD/Manual to show you along with the machine.So you can learn this from the existing documents to deepen your knowledge and understanding. Anyhow there are another way is through internet video face to face for machine teaching, because of the high development in internet,the world has become smaller and you can easy catch us if any assistance needed .
