Hot!!! Manufacturer Supply Low Price VG Series Stainless Steel Oil, Air, Hydraulic, Water Pressure Gauge Manometer

FOB Price

US$ 5 - 50 / Piece

1 Piece(Min. Order)

Port Xi'an Shanghai or other
Payment TermsT/T L/C D/P D/A Credit Card PayPal

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Place of Origin	Shaanxi, China		Brand Name	GX or OEM
Model Number	VG series

Product Description

Hot!!! Manufacturer supply low price VG series Stainless steel oil, air, hydraulic, water Pressure Gauge manometer

Product Description

Introduction

VG series pressure gauges are expressly designed to provide reliable pressure measurements in harsh and demanding industrial and OEM environments, particularly where pulsation and vibration are a concern. The gauges are filled with glycerin to offer a dampening effect, while reducing pointer flutter, as well as offering significant shock reduction to instrument-grade components. They also lubricate internal components, effectively reducing risk of corrosion. The liquid-filled gauges feature a ventable top fill plug and can be mounted on either a horizontal or vertical plane. Units are hermetically sealed for reliable operation in harsh or dirty environments, while reducing the chance of leaks and ease of refilling in the field.

Feature

Glycerin or silicone oil filled

Copper alloy internal components

Hermetically sealed

Appliation

Oil, gas and petrochemical refineries

Chemical processing plants

Marine environments

OEM process control

Commercial and industrial machinery and equipment

Parameter

VG series pressure gauge
Model NO	Diameter	pressure range	accuracy(%)	scale Unit(option)	mounting	application
VG60	60mm(2.5')	-100MPa~-1MPa~0	2.5, 1.6, 1.0 option	Pa, Psi,Bar, torr, ATM, mmHg, inHG, Kgf/m2	bottom	gas, liquid, steam, etc
VG60-1					back
VG100	100mm(4')	-6MPa~-1MPa~0			bottom
VG100-1					back
VG150	150mm(6')	-24MPA~-1MPa~0			bottom
VG150-1					back

Dimension

Type	D	H	H2	B	D2	d0	d	L	H1
VG60	Ø60	32	13	55			M14x1.5	14	22
VG60-1	Ø60	32	0	65	4.5	76	M14x1.5	14	22
VG100	Ø 100	44	18	90			M20x1.5	20	27
VG100-1	Ø 100	44	30	90	5.5	118	M20x1.5	20	27
VG150	Ø 150	44	18	120			M20x1.5	20	27
VG150AT	Ø 150	44	55	95	5.5	165	M20x1.5	20	27

Product pictures

Packaging & Shipping

Our Services

The quality principle: Quality is the best sales

Payment :We accept T/T, PayPal, Western Union, MoneyGram , Escrow

Shipping:

1.All parts will be shipped out within 1 - 3 working days after comfirm the payment

2. DHL / FEDEX / UPS / EMS / TNT / China Post /Aramex

3.We are not responsible for force majeure accidents, delays or other issues, like the shipping service.

4.Any import fees or charges are afforded by the buyers

Service :

1.Provide you one-stop service of electronic components

2. Competitive price advantage help to save your purchase cost and bring in you more profits

3. Having advanced e-commerce capabilities

4. Quick and accurate delivery and flexible logistics support

5. Personalized service, based on your programs and ideas to serve you
