Tire retreading machine/ automatic continuous waste tire/tyre recycling pyrolysis plant with best price

Name

Size(Diameter*length)

Quantity of tire

Vulcanizing tank

1.5x1.5M

eight tire

Function

Tyre preheating for vulcanization with wind cooling cycle motor

Power

35kw

Heating way

Electricity heating, guiding oil heating, steam heating

Main parts

Low voltage electrical control system:Zhengtai

Name

Inflatable tyre grinding machine

Model

FXM-C

Specifications

15",16",20",22.5"

Outside size

1.6x1.8x2.1M

Weight

1150KG

Technical parameter

(1) Grinding head motor power: 11KW

(2) Rotation tyre matching power: 2.2kw

(3) Grinding head of left and right matching power: 0.55kw

(4) Grinding head of front and back matching power: 0.37kw

Function

(1) For tyre rough surface radian grinding

(2) Equipped with tyre shoulder side polishing and tyre explosion-proof function

Main component parts

Low voltage electrical control system: Siemens;

Air cylinder: international brand Taiwan------ Airtac

Name

Rubber powder collecting tank

Model

FXM-B

Outline dimension

1.6x0.78x2.0M

Weight

220kg

Technical parameter

Ventilation motor: 3kw

Function

(1) For absorption of waste soo and smoke after grinding of tire grinding machine

(2) Large capacity, smoke dust collection, convenient collection, energy-saving and health

Main component parts

Low voltage electrical control system: Siemens;

Name

Inflatable tread pressing machine

Model

FTT-B

Specification

15",16",20", 22.5"

Weight

850kg

Technical parameter

1)Press roller matching power: 0.55kw

2)Press wheel matching power: 0.37kg

Function

For carcass and tread pressing,with tire inflation explosion-proof function

Main part

Low voltage electrical control system:Zhengtai

Name

Rim disassembling machine

        Model

                       LJC-A

    Specification

                  15",16",20", 22.5"

Outline dimension

                      1.5x1.3x0.8M

         Weight

                        100KG

       Function

                      For disassembling of rim

Main part

Low voltage electrical control system:Zhengtai

Name

Envelope disassembling machine

Model

LJJ-A

Specification

15",16",20",22.5"

Outline size

2.2x1.5x1.6M

Weight

350KG

Function

For envelope disassembling before and after tire vulcanizing.,  applicable to many kinds of tire.

Main part

Low voltage electrical control system:Zhengtai

name

Buffer rubber strip extruder

model

LJJ-A

specification

20kg/h

Outline dimension

1.0x0.5x0.9M

weight

80KG

Power

1.5KW

Function

Necessary equipment for tire retreading process

Main part

Low voltage electrical control system:Zhengtai

Name

Rubber cement mixing tank

Model

XJB-B

Specification

100L

Outline dimension

0.8x0.85x1.5M

Weight

130kg

Technical parameter

Power : 1.5KW

Function

Used for manufacture of glue adhesion for carcass and tread with uniform character and equipped with explosion-proof motor which can prevent fire

Main part

Low voltage electrical control system:Zhengtai

Name

Multi-function tire repairing machine

Model

TXT-A

Specification

15",16",20",22.5"

Outline dimension

1.2x1.0x1.5M

Weight

100KG

Technical parameter

Motor: 0.18kw

Function

Suitable for tire light grinding and equipped with lifting function during rubberizing

Main part

Low voltage electrical control system:Zhengtai

Name

Tire expanding machine

Model

BJ-KX-20

Specification

Width of suitable tire tread section:100-350mm

Outline dimension

2x1.1x1.2M

Weight

220kg

Technical parameter

Power : 1.5KW

Function

Mainly used to test and repair the inner tire.The lifting of the workbench is controlled by the foot pedal switch.which is convenient to operate.

Main part

Low voltage electrical control system:Zhengtai

Name

Tire trimming cutting machine

Model

BJ-QG

Outline size

1.15x0.6x1.2M

Weight

56kg

Technical parameter

Power : 1.1KW

Function

Mainly used for the cutting of medium pad adhesive during tire retreading.Movement of the motor is controlled by foot pedal switch,which is convenient and safe to operate.

Main part

Low voltage electrical control system:Zhengtai
