RS485 Ultrasonic Fluid Liquid Beer Flow Meter
- Shanghai or other
- T/T L/C D/P D/A Credit Card PayPal
You May Like
-
4~20mA OCT Pulse RS485/232 Inline Ultrasonic Water Flow Meter
-
Handheld Ultrasonic Water Flow Meter
-
OCT Pulse Diesel Fuel Alcohol Water Digital Flow Meter Supplier
-
Digital Oil Fuel Ultrasonic Flow Meter
-
4~20mA Digital Inline Pipe Type Brass Water Flow Meter
-
Insertion Digital Sensor Ultrasonic Flow Meter Clamp
Product Details
| Place of Origin | Shaanxi, China | Brand Name | GX Support OEM | |
| Model Number | GXUF6000I |
Product Description
RS485 ultrasonic fluid liquid beer flow meter
Description of beer flow meter
GXUF6000I series flow meter usually is used to long-term measure at field. It’s easy to operate and easy to install without cut off the pipe. Both the sensor and the host can be installed on the pipes. The protect grade is IP68. KUF6000I also can use as a calorimeter, if the temperature sensor is added.
Features of liquid flow meter
- High accuracy up to 1.0%
- Wide range of flow rate and pipe diameter DN15 to DN6000
- High reliability working life is up to 10 years
- Huge storage function
- Remote transmission and net work transmission
- Easy to used for calorimeter
Applications of fluid flow meter
Parameter of fluid liquid beer flow meter
Parts | Detail | |
Host part | Theory | Ultrasonic time gap |
Accuracy | ±1.0% | |
Option method | 4-keyboard support magnetic | |
Signal output | 1 channel 4~20mA @ 0.1% current loop back, the maxim load resistor up to 1000 ohm | |
1 channel OCT pulse output (default pulse width is 200ms, and can be modify between 6 to 1000ms) | ||
1 channel relay output (3A@220V) | ||
Signal input | 3 channel 4-20mA current loop back @0.1% circuit used to collect Temp. Pressure and liquid level etc. | |
1 channel mV input use to pt100 for calorimeter | ||
Digital port | RS485 support Mod-bus protocol and support firmware update | |
Cable | Special cable for RS485 the range up to 1000m | |
Suit pipe | Pipe material | Steel, cast iron cement, copper, PVC, Aluminum, glass, etc. |
Dimension | 15~6000mm | |
Sensor position | It is better the sensor fix at the position of at least 10D far away to stream, or 5D far away to stream, at least 20D far away from the pump outlet. | |
Suit flow | Medium | Water, sea water, waste water, liquid alcohol, beer, gas, oil, etc. |
Temperature | -30~160°C | |
Turbidity | 10000pm not so much baubles | |
Flow speed | 0~±10m/s | |
Environment | Temperature | Host: -20~60°C; Sensor: -30~160°C |
Humidity | Host: 85%RH; Flow sensor: IP68, less than 2m under water | |
Power supply | DC8~36V or AC85~265V(optional) | |
Consumption | 1.5W | |
Our Services
Sensor can be customized by your special request, We can supply technical consulting service for your user.
The quality principle: Quality is the best sales
Payment: We accept T/T, PayPal, Western Union, MoneyGram , Escrow
Shipping:
1. All parts will be shipped out within 1 - 3 working days after confirm the payment
2. DHL / FEDEX / UPS / EMS / TNT / China Post /Aramex
3. We are not responsible for force majeure accidents, delays or other issues, like the shipping service.
After-sales service
We can offer good technical support and good warranty for you after service as professional manufacturer.
Warranty: One year
During the warranty, if the goods after delivery are damaged with error caused only by itself quality problem, the goods can be returned for free repair and maintenance. however, if the goods is damaged with error caused by user’ s man-made and force majeure factor, we will be not responsible for free repair and maintenance.
GUANGXING pressure, level and flow Instruments has been certified with ISO 9001 (2008)achieved GB/T19001-2008/ISQ9001:2008, GJB 9001B-2009, CE and RoHS, intrinsic safety explosion-proof and isolated safety explosion-proof certification. we developed a lot of sensor products, such as a pressure sensor / transducer / sensor, level transmitter / ultrasonic level meter / ultrasonic flow meter, etc. Our products are widely applied in the fields of chemical industry, petroleum, pharmacy, electricity, municipal works, environmental protection, food and paper-making.
We have the key technology and development center of advanced sensors, and we cooperation with Northwestern Polytechnical University, Xi'an Jiao Tong University and other colleges and universities. Product quality is the life of enterprise, customer demand is our existence!
