7GX-9.0Q 4-stroke MIHENG 12HP Gasoline Outboard Motor(4HP-20HP)

FOB Price

Negotiable / Carton

1 Carton(Min. Order)

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

12hp, 4stroke,9kw,electric start/hand start,shaft connection,,direct injection ,energy efficient

Direct Injection, Energy Efficient

Owner of 7 national-level IPR .

duct:

2.DEMO FIGURE

3.Technical Specifications

MODELS	7GX-9Q Gasoline outboard engine
ENGINE TYPE	SINGLE CYLINDER, HORIZONTAL TYPE, FOUR STROKE, AIR COOLED, OHV
Bore x Stroke (mm x mm)	90×66mm×mm
Displacement (L)	0.420L
Rated Speed of Output Shaft	1560r/min
Max.torque(N•m/rpm)	26.5N.m/2500r/min
Fuel Consumption(g/kW•h)	≤395
Power	Rated Output KW/Ps	9.0KW (12P)
Direction of Output Rotation	Anticlockwise (from the output side)
Valve Clearance (mm)	Intake valve :0.1-0.15mm Exhaust valve: 0.15-0.20mm
Starting Way	Recoil Start/Electric Start
Fuel	Fuel Capacity(L)	6 L
	Mark	93#
Engine Lubrication	Method of Lubrication	Pressure Splash Compound
	Lubrication Oil	SAE10W-30, Level CC above
	Lubrication Oil Capacity(L)	1.1L
Engine Size (LxWxH) (mm)	405×450×443
Engine Net Weight (Kg)	≤32Kg
Machinery Net Weight (Kg)	≤68Kg
Speed of Impeller	1560r/min
Diameter of Impeller	340mm
Transmission Fluid	Middle Duty Industrial Gear Oil HL-20
Transmission Capacity	3L
Applicable Scope	6-10Meters Ship,Maximum load 2tons

4.Functions added

5.Product details

6.Modern workshop and new office.

7.Certificated

8.MIHENG outboard engine

9.Comparison between old and new type of outboard engines

10. Delivery

11.Made in china.
