7GX-14.7Q-QL 20hp 4strokes MIHENG Outboard Motor Long Shaft

FOB Price

Negotiable / Carton

1 Carton(Min. Order)

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Direct Injection, Energy Efficient

Owner of 7 national-level IPR .

duct:

2.DEMO FIGURE

3.Technical Specifications

MODELS	7GX-14.7Q-QL gasoline outboard engine
ENGINE TYPE	V-DOUBLE CYLINDERS
Bore x Stroke (mm x mm)	78×71 mm×mm
Displacement (L)	0.678L
Rated Speed of Output Shaft	1560r/min
Max.torque(N·m/rpm)	43.5N.m/2500r/min
Fuel Consumption(g/kW·h)	≤360
Power	Rated Output KW/Ps	14.7KW(20P)
Direction of Output Rotation	Anticlockwise (from the output side)
Valve Clearance (mm)	Intake valve :0.1-0.15mm Exhaust valve: 0.15-0.20mm
Starting Way	Recoil Start/Electric Start
Fuel	Fuel Capacity(L)	_——
	Mark	≥90#
Engine Lubrication	Method of Lubrication	Pressure Splash Compound
	Lubrication Oil	SAE10W-30, Level CC above
	Lubrication Oil Capacity(L)	1.5L
Engine Size (LxWxH) (mm)	455×400×450
Engine Net Weight (Kg)	≤45Kg
Machinery Net Weight (Kg)	≤81Kg
Speed of Impeller	1560r/min
Diameter of Impeller	380mm
Transmission Fluid	Middle Duty Industrial Gear Oil HL-20
Transmission Capacity	3L
Applicable Scope	8-14 Meters Ship

4.Functions added

5.Product details

6.Modern workshop and new office

7.Certificated

8.MIHENG outboard engine

9.Comparison between old and new type of outboard engines

10. Delivery

11.Made in china.
