rising bollards /traffic barriers/car park barriers

Product Application

      The automatic Bollard is an electric-hydraulic-mechanically operated retractable bollard system.
The system can be quickly and easily operated. It is suitable for both security and access control applications.
The system is designed to bring desired environmental and aesthetic enhancements to perimeter security, securing perimeter access without providing a sense of social disorder and active alarm measures. The system is designed to withstand impacts and still operate, giving high security levels to all sites. It is ideal for university campuses, pedestrian walkways, parking lots, government buildings, sports stadiums, amusement parks, airports, shopping centers, hospitals, and apartment complexes.

The whole size of road block (Tip and LED light optional)168、219、275mm,, rising height : 600mm（select 300~800mm）. It can be linked with gate control system or used separately . The whole system is made up of main machine case , hydraulic transmission station and electronic control . We can offer custom made service to meet client ‘s requirement 。It is a special design used to prevent unauthorized vehicle from breaking into sensitive areas; practicability, reliability and high safety

Electronic Control  Parts

1) System control :Electronic hydraulic
2) Power supply :220/380V
3) System Power (w):1.5KW、2.2KW、3.75KW、5.5KW
4) Rising time :3-6s (Adjustable)
5) Fallowing time : 3-6s (Adjustable)
6) Working Temperature: -25℃~75℃

Bollard system connection
7)Storage environment：10℃~65℃, waterproof, moistureproof, dustproof
8)Color : Different color and grade of reflective film is available
9)Material :304 stainless steel ,A3 carbon steel
10)Bollard size(mm) :L500XW500XH870, rising height 600mm (custom made )
11)Diameter of bollard :219mm , thickness of bollard 6mm (8mm, 10mm,12 mm custom made )
12)weight :180 kg

Product Features:：
1 Solid and endurable structure
2. The system is safe, reliable and stable
3 Perform exactly and operate steadily, making the barrier low noise
4 The working environment is -20°C to 50°C
5 Low-pressure hydraulic driving mode making the barrier Low trouble rate, high reliability, long life cycle,

6 Easy maintenance, and the rate is low

7 Can combine with other control equipment making the barrier auto control

8 In case of electric failure or trouble, the movable barrier can be manually operated to return to the horizontal position, making the cars pass smooth
