Home > Products > pressure vessel > Super Quality High Pressure Chemical Equipment

Super Quality High Pressure Chemical Equipment

FOB Price

US$ 1 - 10,000 / Set

1 Set(Min. Order)

Port Shanghai
Payment TermsT/T L/C D/P D/A Credit Card PayPal

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Condition	New	Place of Origin	Jiangsu, China
Brand Name	SY	Model Number	as per design
Dimension(LWH)	customized	Capacity	30L-80000L
Weight	0.5-50T	After-sales Service Provided	Engineers available to service machinery overseas

Product Description

Super quality high pressure chemical equipment

TRADE ASSURANCE VARIOUS KINDS OF REACTORS

Dear Customers:

We have Trade Assurance granted by , which means you will receive 100% refund for all of the orders if the products do not meet your quality requirement or delivery time!

We have ASME certificates and Chinese pressure vessel design and manufacturing certificates from grade 1 to grade 3

Our pressure vessel (electric, steam and thermal oil heating) is composed by cover, cylinder, jacket, stirrer, gland seal drive and support. The body and parts contacting with the materials are all made by Ocr18Ni9 or 1Cr18Ni9Ti acid-resisting stainless steel plate.
We are the professional stainless steel kettle manufacturer as well as all specifications of non-standard chemical and light mechanical equipment designer and producer. Welcome the enquiries both from home and abroad.

Electric Heating Kettle

Nominal Volume L	Electric Power	Size of Inner Kettle φmm	Jacket Size Φmm	Reducer Model	Electromotor n/kw	Stirring Speed r.p.m
50	4×2 KW	φ400	φ600	BLD 0.8-1	1450/0.8	60-100
100	6×2 KW	φ500	φ700	BLD 1.1-1	1450/1.1	60-100
300	6×4 KW	φ800	φ1000	BLD 2.2-2	1450/2.2	60-100
500	9×4 KW	φ900	φ1100	BLD 3-2	1450/3	60-100
1000	12×4 KW	φ1200	φ1400	BLD 4-3	1450/4	60-100
2000	15×5 KW	φ1400	φ1600	BLD 4-3	1450/4	60-100
3000	15×6 KW	φ1600	φ1800	BLD 5.5-3	1450/5.5	60-100

Steam Heating Kettle

Nominal Volume L	Electric Power	Size of Inner Kettle φmm	Jacket Size φmm	Reducer Model	Electromotor n/kw
30	400	500	0.6	BLD 0.6-1	60-100
50	500	600	0.8	BLD 0.8-1	60-100
100	550	65	1.1	BLD 1.1-1	60-100
150	600	700	2.2	BLD 2.2-2	60-100
200	650	750	2.2	BLD 2.2-2	60-100
300	800	900	3	BLD 3-2	60-100
500	900	1000	3	BLD 3-2	60-100
800	1100	1200	4	BLD 4-2	60-100
1000	1200	1300	4	BLD 4-3	60-100
1500	1300	1400	4	BLD 4-3	60-100
2000	1400	1500	5.5	BLD 5.5-3	60-100
2500	1400	1500	7.5	BLD 7.5-4	60-100
3000	1400	1500	7.5	BLD 7.5-4	60-100
3500	1400	1500	7.5	BLD 7.5-4	60-100
4000	1500	1600	7.5	BLD 7.5-4	60-100
5000	1600	1700	7.5	BLD 7.5-4	60-100
6000	1800	1900	15	BLD 15-5	60-100
18000	2000	2100	15	BLD 15-5	60-100
32000	3000	3200	37	BLD 37-56A	35-59

Since user’s manufacture technique and operation condition vary, the heating type of jacket can be classified as electric-heating bar, steam and thermal oil circulation. The gland seal packing can be filler seal and mechanical seal. The stirrer has anchor, blade, turbo, impeller or gate types. Drilling number and specification or other requirements can be designed and manufactured as per users’ demands.

Why Choose us?

1. Famous Brand in the Industry

2. Best Quality Standard, most competitive Price

3. Fast Delivery time, excellent after-sales service for 2 years.
