API Adaptor
USD $1 - $120
/ Piece
35 Pieces(Min. Order)
- Shanghai
- T/T Credit Card
You May Like
Product Details
| Place of Origin | Shanghai, China | Brand Name | AILE | |
| Model Number | HYF-01 |
Product Description
Specifications
API AdaptorLoading and off-loading are easier than ever with AILE's bottom loading adaptor;
API Adaptor
1) Loading and off-loading are easier than ever with AILE's bottom loading adaptor;
2) While loading, a free float poppet design keeps the handle in the closed position as long as the poppet is activated.3) During off-loading, the handle's 2 open positions adjust the flow rate;
4) The lightweight, heavy-duty adaptor is engineered and tested to meet API specifications;
5) The outer end is hard-coated aluminum and rotates to prevent uneven wear sometimes caused by terminal and off-loading couplings;
6) Compatible with the API dry disconnect couplers;
7) The adaptor is constructed following the TTMA standard;
8) 4" tank truck flange and mounting lugs for Aile interlock valve;
9) Materials:
a) Body: aluminum alloy
b) API adaptor end: hard-coated aluminum
c) Poppet: stainless steel
d) Shaft and latch plate: stainless steel
e) CAM: aluminum bronze
f) Handle: bronze
g) Seals: fluorocarbon and buna-N
h) Standard: meets API R P 1004 specifications, the TTMA standard;
10) Replacement parts:
a) Shaft seal
b) Cover seal
c) Flange seal
d) Handle
e) API adaptor end
11) Ordering specifications:
a) Products: HYF-01
b) Type: standard
c) IN.: 4.00
d) Weight: 6.00kg
