High Quality and Low Price Tractor Truck Tractor Trailer

Truck Model

Dimension(Lx W xH)(unloaded)(mm)

6800x2490x3668

Approaching angle/Departure angle(°)

16/70

Overhang(front/rear) (mm)

1500/700,725

Wheel base (mm)

3200+1400,3225+1350

Max speed(km/h)

102

Curb weight(kg)

11930

Loading Weight(kg)

40000

Engine

(Steyr technology, made in China)

Model

WD615,water-cooled,four strokes,6 cylinders in line with water cooling,turbocharged and intercooling, directly injection

Fuel type

Diesel

Horse Power, max(kw/rpm)

371HP,

Emission

EURO3

Fuel tanker capacity(L)

400

Transmission

Model

Brake system

Service brake

Dual circuit compressed air brake

Parking brake

spring energy, compressed air operating on rear wheels

Steering system

Model

ZF8098

Front axle

HF7

Rear axle

ST13

Color

White, red,Yellow .

Tyre

295/80R22.5

Electrical system

Battery

2X12V/165Ah

Alternator

28V-1500kw

Starter

7.5Kw/24V

Cab

all-steel forward control,55ºhydraulically tiltable to the front, 2- arm windscreen wiper system with three speeds, laminated windscreen with casted-in radio aerial, hydraulically damped adjustable driver’s seat and rigid adjustable co-driver’s seat, with heating and ventilating system, outer sun visor, adjustable roof flap, with stereo radio/cassette recorder, safety belts and adjustable steering wheel, air horn, with 4-point support fully floating suspension and shock absorbers
