Gabion box

FOB Price

US$ 15 - 20 / Square Meter

1000 Square Meters(Min. Order)

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Place of Origin	Hebei, China	Brand Name	Dayu
Model Number	YX-GABION	Material	Other, Galvanized Iron Wire, Galvanized Iron Wire
Type	Perforated Mesh	Application	Gabions
Hole Shape	Hexagonal	Aperture	60X80mm,80X100mm,100X120mm
Wire Gauge	1.9mm-4.0mm

Yuanxi gabion Iwe can provide very kinds of material:
1.electro wires gabion
2.hot-dipped wires gabion
3.Galfan
4.pvc-coated

Gabions Installation support

Pneumatic lacing tools and high-strength lacing rings, which dramatically reduce the labour time and effort required in installing the gabion units
Gabion closing tools to assist in the installation process
Specialist non-standard sizes to ensure supply costs are reduced for a specific gabion structure, on-site installation training for major projects for either installers or site supervisors (including quality checklists)
Tensioning tools to assist in achieving a high quality finish in the installed structure
Preformed braces to assist with achieving a high standard

Heavy hexagonal mesh
Mesh Opening (MM)	Iron Wire Diameter (MM)	(PVC Wire)/ Inside diameter/Outer diameter(MM)	Roll Width (M)
60X80	2.0-2.8	2.0/3.0-2.5/3.5	4.3
80X100	2.0-3.2	2.0/3.0-2.8/3.8	4.3
80X120	2.0-3.2	2.0/3.0-2.8/3.8	4.3
100X120	2.0-3.4	2.0/3.0-2.8/3.8	4.3
100X150	2.0-3.4	2.0/3.0-2.8/3.8	4.3
120X150	2.0-4.0	2.0/3.0-3.0/4.0	4.3

Anping Yuanxi Metal Products Co., Ltd.: Contact namexiangmeng zhang
Chat Now; Phone86-318-7711307; AddressYuanxi developing zone, Hengshui, Hebei
