Optical Fiber Optic Fusion Splicer for CATV Telecom/ Fibre Optic Cable Splicing Machine Fiber Fusion Splicer Price
You May Like
Product Description
Withe Fiber Holders
Digital fusion splicer with automatic focus function
Fiber core can be display clearly
Single X or Y view and X & Y view simultaneously
Digital fusion splicer with automatic focus function
Fiber core can be display clearly
Single X or Y view and X & Y view simultaneously
Auto detect cleaved endface fault
Display fiber cleaved and offset angle
Display core and clad offset
5.6 inch TFT color LCD monitor with clear digital image display
USB & VGAinterface
Software upgrade via USB interface
Model | with Fiber Holders |
Applicable fibers | SM (ITU-T G.652), MM (ITU-T G.651), DS (ITU-T G.653), NZDS (ITU-T G.655) |
Fiber cleaved length | 10 ~16mm (Coating diameter |
Fiber diameter | Cladding diameter:80 ~150µm , Coating diameter:100 ~1000µm |
Auto focusing | Available |
Fiber aligning method | Core aligning, clad aligning, manual aligning |
Average splice loss | 0.02dB (SM), 0.01dB (MM), 0.04dB (DS), 0.04dB( NZDS) |
Splicing time | Typical 9 sec,with standard SM fiber |
Heating time | Typical 36 sec |
Applicable sleeves | 60mm, 40mm and a series of micro sleeves |
Tension test | 2N(option) |
Electrode life | 5000 |
Battery capacity | Typical 400 cycles (splice and heat) |
Monitor | 5.1 inch TFT color monitor |
Terminal | USB 1.1 and VGA , software upgrade via USB interface |
Operating condition | 0 ~ 5000m above sea level, 0 ~ 95%RH and -10~50oCC, respectively, Max. wind velocity of 15m/s |
Splicing mode | Auto ,normal |
Fiber cleaved angle threshold set | 0.1 ~ 10.0 oC , 0.1oCstep |
Power supply | Li-battery 11.8V , AC100-240V DC12.6V/5.0A |
Dimension | L169*W152*H155mm |
weight | 2.4kg 2.9kg(battery) |
