Home > Products > Miniature circuit breaker > High Quality ZYC16-32 Miniature Circuit Breaker,power Circuit Breaker
High Quality ZYC16-32 Miniature Circuit Breaker,power Circuit Breaker
- NINGBO/SHANGHAI
- T/T
You May Like
-
Attentive Service ZYC17-63 Miniature Circuit Breaker,MCB,4 Amp Circuit Breaker
-
ZYC18-100 Miniature Circuit Breaker,plug-in Type Circuit Breaker,mcb Switch for Protection
-
Competitive Price ZYI 1-100 Isolating Switch , Disconnector Isolator Switch
-
ZYI 2-125 Isolating Switch ,1p,2p,3p,4p Disconnector Isolator Switch
-
ZYI 16-63 Isolating Switch , Isolator Switch1,2,3,4 Phase Type of Isolator Switch
-
High Quality ZYL1-63 RCCB/Residual Current Circuit Breaker,Electrical Circuit Breaker
Product Details
| Place of Origin | Zhejiang, China | Brand Name | WEHOPE | |
| Model Number | mini circuit breaker ZYC16-32 | Type | Mini | |
| Poles Number | 1 |
Product Description
Specifications
1.Competitive price2.OEM /ODM
3.High quality
4.Attentive Service
5.Customization & Personalization
| MODEL | MINI CIRCUIT BREAKER ZYC16-32 |
| Pole No. | 1P+N |
| Rated voltage | AC 230 |
| Rated current | 6,10,16,20,25,32(A) |
| Tripping curve | B,C,D |
| Rated breaking capacity(Icn) | 4.5kA |
| Rated frequency | 50/60Hz |
| Terminal connectoin height | H1=19mm H2=22mm |
| Electro-mechanical endurance | 4000 CYCLES CONTACT POSITION INDICATION |
| Connection terminal | SCREW TERMINAL PILLAR TERMINAL WITH CLAMP |
| Connection capacity | RIGID CONDUCTOR UP TO 10MM² |
| Fastening torque | 1.2Nm |
| Installation | ON SYMMETRICAL DIN RAIL 35MM PANEL MOUNTING |
Structure and Usage
1.The state-of-art design
Elegant appearance; cover and handle in arc shape make comfortable operation.
Contact position indicating window
Transparent cover designed to carry label.
2.Handle central-staying function for circuit fault indicating
In case of overload to protected circuit, MCB hand le trips and stays at centra l position, which enables a quick solution to the faulty line. The handle cannot stay in such position when operated manually.
3.Handle padlock device
MCB handle can be locked either at ON position or at OFF position to prevent unwanted operation
of the product.
Product's advantage
1.our products have an excellent ratio between price and quality ,you can possess them by competitive price and high quality;
2.The fast and flexible production form aim at the customer require;
3.The deliveries exactly in accordance with customer orders
4.The fast transportation.
Order note
1,Following items should be marked when ordering
2,Product Name,Model&Frame level
3,Pole
4,Tripping characteristic and rated current
5,Quantity
6,Ordering sample
power circuit breaker power circuit breaker power circuit breaker power circuit breaker power circuit breaker power circuit breaker power circuit breaker power circuit breaker power circuit breaker power circuit breaker power circuit breaker power circuit breaker power circuit breaker power circuit breaker power circuit breaker power circuit breaker power circuit breaker
Packaging:
The packaging of the power circuit breaker is standard export carton or according to your requirements.
Shipping:
normally ocean shipping
The delivery date of the power circuit breaker is within 20-30 days after receiving payment.
Our service
1.Your inquiry related to our products or prices will be replied in 24hrs.
2.Well-trained and experienced staffs to answer all your enquires in fluent English.
3.OEM&ODM, any your customized breakers we can help you to design.
4.Distributorship are offered for your unique design and some our current models.
5.Protection of your sales area, ideas of design and all your private information.
FAQ
Q 1. what's the payment term?
A. We accept TT, 30% deposit and 70% balance agaisnt copy of BL, Western
Union ,L/C is ok!
Q 2. how's the delivery time ?
A. usually it will take about 15~20 days for production
Q 3. tell me the standard of package?
A. For the small capacity, it use carton.
Q 4.Could you offer Form A or C/O ?
A. It totally not a problem. We can prepare relative documents to forgin affairs office or other office to apply for this certificate.
Q 5.Would you accept to use our logo ?
A.If you have good quantity,it absolute no problem to do OEM.
Q6. How about the transport?
A. If the number of goods is small we usually use TNT, TNT-DHL,EMS,DHL and some express you offered. If the number of the goods is big usually we use the FWD you offered. Either by sea or by air is OK.
Q7. What is the different between HOUPU and WEHOPE ?
A. HOUPU is my company name and the WEHOPE is brand name of our products.
